Clarion PP-3000M-A User Manual

929-0390-81
- M14 -
ELECTRICAL PARTS LIST
CD PWB(BM1) section
C1 168-1052-78 1uF
C3 168-1042-78 16V 0.1uF
C4 043-0559-90 6.3V 22uF
C5 168-1032-55 0.01uF K
C6 042-1702-90 6.3V 100uF
C7 168-1052-78 1uF
C9 168-1052-78 1uF
C11 168-1052-78 1uF
C12 042-0671-01 10V 47uF TA
C13 168-1052-78 1uF
C14 168-1042-78 16V 0.1uF
C15 168-1052-78 1uF
C16 043-0559-90 6.3V 22uF
C17 168-1032-55 0.01uF K
C18 168-1052-78 1uF
C19 043-0559-90 6.3V 22uF
C20 168-1042-78 16V 0.1uF
C21 168-1032-55 0.01uF K
C23 043-0559-90 6.3V 22uF
C24 043-0559-90 6.3V 22uF
C25 168-4732-78 0.047uF K
C26 166-4711-50 470pF CH
C28 168-4732-78 0.047uF K
C29 166-4711-50 470pF CH
C30 166-1007-50 10pF CH
C31 166-1007-50 10pF CH
C32 168-1042-78 16V 0.1uF
C33 168-2222-55 2200pF K
C34 168-1042-78 16V 0.1uF
C35 168-1042-78 16V 0.1uF
C36 168-1042-78 16V 0.1uF
C37 168-6822-55 6800pF K
C39 168-1042-78 16V 0.1uF
C40 168-3332-78 0.033uF K
C41 168-1042-78 16V 0.1uF
C42 168-1042-78 16V 0.1uF
C43 168-1042-78 16V 0.1uF
C45 168-1042-78 16V 0.1uF
C46 168-1042-78 16V 0.1uF
C48 168-1042-78 16V 0.1uF
C49 168-1042-78 16V 0.1uF
C50 168-1042-78 16V 0.1uF
C51 168-1042-78 16V 0.1uF
C52 168-5622-55 5600pF K
C53 168-1042-78 16V 0.1uF
C54 166-6801-50 68pF CH
C55 168-1532-55 0.015uF K
C56 168-1042-78 16V 0.1uF
C57 168-1032-55 0.01uF K
C58 168-1042-78 16V 0.1uF
C59 168-1042-78 16V 0.1uF
C60 168-1522-55 1500pF K
C61 168-3322-55 3300pF K
C62 168-1032-55 0.01uF K
C64 168-1042-78 16V 0.1uF
C65 168-1032-55 0.01uF K
C67 168-1032-55 0.01uF K
C69 168-1532-55 0.015uF K
C70 166-4701-50 47pF CH
C71 168-1042-78 16V 0.1uF
C72 168-1042-78 16V 0.1uF
C74 166-6097-50 6pF CH
C75 168-1042-78 16V 0.1uF
C76 168-5622-55 5600pF K
C77 168-1032-55 0.01uF K
C79 166-1501-50 15pF CH
C80 166-1501-50 15pF CH
C101 043-0563-90 16V 47uF
CCT1 050-0145-59 1/16W 22 ohm x4
CCT2 050-0145-54 1/16W 47k ohm x4
CCT3 050-0145-54 1/16W 47k ohm x4
CCT4 050-0145-55 1/16W 10k ohm x4
CCT5 050-0140-55 1/32W 2.2k ohmx4J
D1 001-4301-14 HZU 3.0B1
D2 001-0367-91 1SS226
D3 001-4301-16 HZU 3.3B1
D4 001-4301-18 HZU 3.6B1
D5 001-2612-90 RB520S-30
D6 001-2612-90 RB520S-30
D7 001-9210-50 AVR-
M1608C270MTAAD
D8 001-9210-50 AVR-
M1608C270MTAAD
IC2 052-5071-30 TMP91FY22IFG-
6R96
IC3 051-6733-00 TC94A73MFG-201
IC4 051-6060-08 BD7961FM-E2
IC5 051-5445-08 BD5227G-TR
IC8 051-9402-78 BR93L56RFVM-W
IC9 051-6072-08 BD7931FE2
IC10 051-5833-00 GP1S093HCZ
IC11 051-3392-90 S-1323B15NB-
N8ATFG
J1 074-1237-69 19PIN
J2 074-1201-65 15P
J3 074-1138-56 6P
J4 074-1100-61 SOCKET 11P
J5 074-1201-61 11P SOCKET
Q1 060-0252-01 PT4850F
Q2 125-0021-91 DTA114EUA
Q3 198-3018-00 2SK3018
Q4 190-2060-00 2SA2060
Q8 190-2060-00 2SA2060
Q9 125-9026-90 IMF29
Q10 125-2027-91 DTC114EUA
Q11 125-0021-91 DTA114EUA
Q12 125-2027-91 DTC114EUA
Q13 125-9026-90 IMF29
R1 119-6811-15 1/10W 680 ohm
R2 119-6811-15 1/10W 680 ohm
R3 032-0163-91 1/2W 10 ohm
R4 032-0163-91 1/2W 10 ohm
R5 119-2231-15 1/10W 22k ohm
R6 116-1001-15 1/4W 10 ohm
R7 119-1021-15 1/10W 1k ohm
R8 116-1591-15 1/4W 1.5 ohm
R9 119-2231-15 1/10W 22k ohm
R10 119-4711-15 1/10W 470 ohm
R11 119-2211-15 1/10W 220 ohm
R12 119-6811-15 1/10W 680 ohm
R13 119-1011-15 1/10W 100 ohm
R14 119-2231-15 1/10W 22k ohm
R15 119-8231-15 1/10W 82k ohm
R16 119-1041-15 1/10W 100k ohm
R17 119-1041-15 1/10W 100k ohm
R18 119-1041-15 1/10W 100k ohm
R19 119-1041-15 1/10W 100k ohm
R20 119-1041-15 1/10W 100k ohm
R21 119-2221-15 1/10W 2.2k ohm
R22 119-4711-15 1/10W 470 ohm
R23 119-1051-15 1/10W 1M ohm
R24 119-2211-15 1/10W 220 ohm
R25 119-2211-15 1/10W 220 ohm
R26 119-1041-15 1/10W 100k ohm
R27 119-1051-15 1/10W 1M ohm
R28 119-1041-15 1/10W 100k ohm
R29 119-1041-15 1/10W 100k ohm
R30 119-4701-15 1/10W 47 ohm
R31 119-2201-15 1/10W 22 ohm
R32 119-1051-15 1/10W 1M ohm
R33 119-2211-15 1/10W 220 ohm
R35 119-1051-15 1/10W 1M ohm
R36 119-4721-15 1/10W 4.7k ohm
R37 119-4731-15 1/10W 47k ohm
R38 119-2231-15 1/10W 22k ohm
R39 119-1041-15 1/10W 100k ohm
R40 119-4721-15 1/10W 4.7k ohm
R41 119-4731-15 1/10W 47k ohm
R43 119-4731-15 1/10W 47k ohm
R44 119-2201-15 1/10W 22 ohm
R45 119-1511-15 1/10W 150 ohm
R46 119-4721-15 1/10W 4.7k ohm
R48 119-1041-15 1/10W 100k ohm
R49 119-0000-05 1/10W 0 ohm JW
R50 119-2211-15 1/10W 220 ohm
R51 119-0000-05 1/10W 0 ohm JW
R52 119-1041-15 1/10W 100k ohm
R53 119-5621-15 1/10W 5.6k ohm
R55 119-3341-15 1/10W 330k ohm
R56 119-4731-15 1/10W 47k ohm
R57 119-2231-15 1/10W 22k ohm
R58 119-0000-05 1/10W 0 ohm JW
R59 119-1511-15 1/10W 150 ohm
R60 119-4731-15 1/10W 47k ohm
R61 119-1041-15 1/10W 100k ohm
R62 119-1041-15 1/10W 100k ohm
R63 119-1041-15 1/10W 100k ohm
R64 119-1011-15 1/10W 100 ohm
R65 119-1041-15 1/10W 100k ohm
R66 117-5611-15 1/8W 560 ohm
R67 117-7511-15 1/8W 750 ohm
R68 117-7511-15 1/8W 750 ohm
R69 119-1041-15 1/10W 100k ohm
R81 116-1591-15 1/4W 1.5 ohm
R211 119-1041-15 1/10W 100k ohm
R212 119-1041-15 1/10W 100k ohm
S1 013-7416-50 SW SPVL110200
S2 013-7416-50 SW SPVL110200
S3 013-7416-50 SW SPVL110200
S4 013-7415-50 SPVG110400
X1 061-3534-90 16.92MHz
X3 060-1545-90 20MHz
PWB 039-3083-21 PWB(WITHOUT
COMPONENT)
Sensor-L-PFC(BM2) section
PT1 060-0252-01 PT14850F
PT2 060-0252-01 PT14850F
PT3 051-5833-00 GP1S093HCZ PWB 039-2467-21 PWB(WITHOUT
COMPONENTS)
Sensor-U-PFC(BM3) section
LED1 001-7077-00 GL4804
LED2 001-7077-00 GL4804
LED3 001-7077-00 GL4804
S5 013-7417-50 ABC1122P161
PWB 039-2466-20 PWB(WITHOUT
COMPONENTS)
REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION
REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION
REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION
