Clarion VRX765VD Service Manual

VRX765VD
VRX766VD
- 5 -
WIRE CONNECTION
CeNET
terminal
Red
White
Red
White
Right
left
Front audio output
terminal
Right
left
Rear audio output
terminal
Right
left
Non fader
output terminal
Gray
Black
Purple
Red
White
Yellow
Yellow
Yellow
White
Red
Video output terminal
TV tuner input terminal or
DVD changer input terminal
Video
Audio (left)
Audio (right)
Visual input
terminal
Optical output
connector
Radio antenna jack
Wireless
Head phone
VTR etc.
4-Channel Amplifier
Right
Left
(2-ZONE
output terminal)
Gray
Rear monitor
Black
Red
Green
Red
White
Yellow
Black
Purple
Purple/Black
Grass-green
Gray
Gray/Black
White
White/Black
Green
Green/Black
Blue/White
Orange/White
Red
Brown
Blue
(+12V main power)
Ground
Rear right +
Rear right -
Parking brake lead
Front right +
Front right -
Front left -
Rear left +
Rear left
-
Amp. turn-on lead
Illumination
+12V accessory
Phone mute
Auto antenna
iPod
(CCA-670-600)
Connector cab
le
20
2 4 6 8
1 3 5 7 9
19
1
2
3
4
5
6
7
8
9
11
12
13
14
15
16
17
18
19
20
LEFT REAR
RIGHT REAR
LEFT FRONT
RIGHT FRONT
S-GND
S-GND
NF LEFT
NF RIGHT
S-GND
S-GND
2ZONE LEFT
2ZONE RIGHT
V OUT GND
V IN GND
VIDEO OUT
VIVEO IN
V-AUDIO GND L
V-AUDIO GND R
V-AUDIO LEFT
V-AUDIO RIGHT
10 12 14 16 18
11 13 15 17
1
2
10
11
12
13
14
15
16
8
7
6
5
4
3
9
Front left +
10
J601
No. Description No. Description
1 SP R/L(+)
3 SP F/L(-)
5 SP F/L(+)
7 SP F/R(+)
9 SP F/R(-)
11 SP R/R(+)
13 SP R/R(-)
15 BACK UP
2 SP R/L(-)
4 PHONE MUTE
6 ACC
8 AUTO ANT
10 REMOTE
12 ILLUMI
14 PARKING BRAKE
16 GND
P201
Description
No.
No.
Description
BACK UP

Clarion VRX765VD Specifications

General

Motorized Screen	Yes
DVD Playback	Yes
CD Player	Yes
Bluetooth	No
Audio Formats Supported	MP3, WMA
Preamp Outputs	3 (Front, Rear, Subwoofer)
Remote Control	Yes
Number of Channels	4
JPEG Playback	Yes
Subwoofer Output	Yes
Auxiliary Input	Yes
HD Radio	No
AM/FM Tuner	Yes
Video Output	Yes
DIN Size	1 DIN
USB Port	Yes
Video Formats Supported	DivX
Power Output	50 watts x 4 channels
Peak Output	50 watts x 4 channels
iPod Compatibility	Yes
Resolution	336, 960 pixels
RMS Power Output	19W x 4 Channels
