Clarion XR2220 User Manual

English
XR2220/XR2420/XR212018
XR2220
Maximum power output
Continuous rated power *
Typical power in bridged mode **
Typical power in 2 Ohm load **
IM distortion
S/N (A-weighted)
Channel separation
Frequency response
Line level input sensitivity
Speaker level input sensitivity
Input impedance
Allowable battery voltage
Size (W x L x H)
280W
65W x 2
190W x 1
95W x 2
0.1%
85dB
60dB
20Hz-30kHz
200mV to 5.5 Volts
400mV to 11 Volts
22kOhm
9.6 to 15.6 Volts
11-5/8” (295mm) x 8-1/2” (217mm) x 2-3/16” (55mm)
* THD 1%, 20Hz-20kHz, into 4 Ohms, @14.4V, all channels driven
** THD 1%, 20Hz-20kHz, @14.4V, all channels driven
XR2120
Maximum power output
Continuous rated power *
Typical power in bridged mode **
Typical power in 2 Ohm load **
IM distortion
S/N (A-weighted)
Channel separation
Frequency response
Line level input sensitivity
Speaker level input sensitivity
Input impedance
Allowable battery voltage
Size (W x L x H)
570W
280W x 1
N/A
400W x 1
0.1%
70dB
Mono
20Hz-30kHz
200mV to 5.5 Volts
400mV to 11 Volts
22kOhm
9.6 to 15.6 Volts
14” (354mm) x 8-1/2” (217mm) x 2-3/16” (55mm)
* THD 1%, 20Hz-20kHz, into 4 Ohms, @14.4V, all channels driven
** THD 1%, 20Hz-20kHz, @14.4V, all channels driven
