3-8 Pod Symbols and Functions
•Seat belt
At start-up, this light and a buzzer come
on for three seconds to remind the
operator to fasten the seat belt. There is no
start interlock.
You should always have your seat belt securely fastened
when operating your lift truck.
• Parking brake
Indicates that the parking brake is
engaged. Anytime the parking brake is on,
the truck can’t be driven because the
Transmission solenoid valves switch is off.
When the parking brake is not set and the
key switch is turned to the OFF position,
the instrument pod will sound.
If the parking brake is set, buzzer and horn will not sound.
• Date & Time
It displays current date and time.
• Hourmeter & Speed
It displays the accumulated operating
hour and traveling speed of truck.
When the traveling speed is less than
0.5km/h, it displays the accumulated
operating hour.
When the traveling speed is more
than 0.5km/h, it displays the traveling
speed.
It can be dispayed in the of km/h or MPH.
