Key/Start Switch
• Connects the battery with all truck operating systems (drive, lift,
and steer electrical circuits) including the horn.
• Connects battery to the diagnostic display.
The key switch must always be turned to the ON position to operate the
truck. When the key is in the vertical OFF position, instruments, drive and
pump motor electrical circuits are disconnected (shut-o), and the key
can be removed. The horn will not operate if the key switch is turned o.
Control Handle
• Controls travel dir
ection and speed, lift, lower, tilt, reach, side-
shift, horn, braking and steering.
• Twist grip or butterfly type speed control for left or right hand
operation.
• Up or down brake application.
• Safety reversing switch on end of control handle.
• 180º rotation for maneuverability.
• Offset steering provides greater visibility for the operator.
Drive Unit
• 24-Volt AC drive motor for increased eciency and duty cycles.
Brakes
• Electronic magnetic parking brake provides safe and secure hold-
ing power.
Operator Controls
Common Truck
