5. Move the air conditioner into position and extend the flexible exhaust duct
to suit your window layout.
NOTE: The length of the exhaust duct is variable between 480mm and
1500mm (adaptors included). Using a shorter length of ducting
uses less energy.
NOTE: The length of duct has been designed to suit the specification of
the air conditioner. Do not use an extension or change to a
different size duct as it may lead to poor performance.
6. The flexible exhaust ducting can
be bent to an angle if followed by
a straight section but tight curves
and kinks must always be
avoided.
7. Extend the two parts of the
window sealing plate and fit into
the window opening, below or
beside the window panel as
shown above.
8. Secure in position by closing the window, or if not secure, wedge or
otherwise secure the window slider plate so that it cannot fall out.
