2
Table of Contents
1 INTRODUCTION
1.1 About the COBD II Code Reader 3
1.2 Safety Precautions and Warnings 3
2. GENERAL INFORMATION
2.1 On-Board-Diagnostics (OBD) II 4
2.2 Diagnostic Trouble Codes (DTCS) 4
2.3 Location of the Data Link Connector (DLC) 6
2.4 OBD II Readiness Monitors 6
2.5 OBD II Monitor Readiness Status 6
2.6 OBD II
T
erminology 6
3. PRODUCT INFORMATION
3.1 Device Description 9
3.2 Specifications 9
3.3 Accessories Included 10
3.4 Navigation Characters 10
3.5 Vehicle Power 10
3.6 Product Setup 10
3.7 Vehicle Coverage 13
4. OBD DIAGNOSTICS
4.1 System Status 14
4.2 Reading Codes 15
4.3 Erasing Codes 16
4.4 Live data 17
4.5 Viewing Freeze Frame Data 18
4.6 Retrieving I/M Readiness Status 19
4.7 Viewing Vehicle Information 21
4.8 Exiting the OBDII Test 22
5. SOFTWARE UPDATES
5.1 Software Downloads 22
6. DECLARATION OF CONFORMITY 23
