Clarke CSS 400 - Parts List

1 Base 1 SD40001 45 Eccentric 1 SD40045
2 Side cover 1 SD40002 46 Hex. socket set screw 1 SD40046
3 Cap head screw 11 SD40003 47 Motor 1 SD40047
4 Body 1 SD40004 48 Switch 1 SD40048
6 Label 1 SD40006 49 Hex. socket head bolt 1 SD40049
7 Cap head screw 6 SD40007 50 spring compression 1 SD40050
8 Socket head screw 1 SD40008 51 Flat washer 2 SD40051
8A Socket head screw 1 SD40008A 53 Table 1 SD40053
10 Label 1 SD40010 54 Hex. socket head bolt 1 SD40054
11 Label 1 SD40011 55 Bracket-tilt 1 SD40055
13 Bush 1 SD40013 57 Knob 1 SD40057
13A Bush 1 SD40013A 58 Cap. head screw 2 SD40058
14 Bolt tensioning 1 SD40014 62 Indicator 1 SD40062
15 Bolster threaded 1 SD40015 63 Support table 1 SD40063
16 Bolster 1 SD40016 64 Spring washer 9 SD40064
17 Blade tension knob 1 SD40017 65 Hex. head bolt 4 SD40065
18 Spring pin 1 SD40018 66 Hex. head bolt 2 SD40066
19 Spring 1 SD40019 68 Hex. head bolt 3 SD40068
20 Retainer 2 SD40020 70 Label warning 1 SD40070
21 Hex. socket head bolt 2 SD40021 71 Plug 1 SD40071
22 Spring bushing 2 SD40022 75 Plain blade holder 2 SD40075
23 Upper arm 1 SD40023 77 Steel housing 1 SD40077
24 Hex. socket head bolt 2 SD40024 78 Right housing 1 SD40078
25 Star washer 2 SD40025 79 Table insert 1 SD40079
26 Upper blade holder 1 SD40026 82 Windpipe 1 SD40082
27 Blade 1 SD40027 83 Windpipe clamp 1 SD40083
28 Hex. soc. head bolt 1 SD40028 84 Balloon seat 1 SD40084
33 Blade guard 1 SD40033 85 Bushing 2 SD40085
34 Lower arm 1 SD40034 86 Bellows 1 SD40086
35 Spring washer 1 SD40035 87 Plastic tube 1 SD40087
36 Ball bearing 2 SD40036 88 Nut 1 SD40088
37 Spring washer 7 SD40037 89 Spring bolt 3 SD40089
38 Hex. nut. 1 SD40038 90 Hex. head bolt 1 SD40090
39 Hex.socket head bolt 1 SD40039 91 Cap. head screw 1 SD40091
40 Link 1 SD40040 92 Flat washer 2 SD40092
40A Link cover 1 SD40040A 93 Spring washer 1 SD40093
41 Bushing 1 SD40041 94 Tapping screw 1 SD40094
44 Lower blade holder 1 SD40044
14
PARTS LIST
For Spare Parts and Servicing, please contact your nearest dealer, or
CLARKE International, on one of the following numbers.
PARTS - 0181 558 6696 SERVICE - 0181 556 4443
PARTS & SERVICE FAX - 0181 558 3622
PARTS AND SERVICE
No. Description Qty Part No. No. Description Qty Part No.
