Page 16 of 49
UL/FM Front Opening Instrument Panel
Figure #9
1 – Emergency Operating Instructions 6 – Overspeed Verification
2 – Automatic / Manual Mode Selector 7 – Overspeed Indication Light
3 – Manual Crank Controls 8 – Oil Pressure Gauge
4 – Overspeed Reset 9 – Voltmeters Battery 1 & 2
5 – Manual Mode Warning Light 10 – Coolant Temperature Gauge
Non-Listed Instrument Panel
1 – Emergency Operating Instructions 4 – Overspeed Reset
2 – Automatic-Manual Mode Selector 5 – Warning Light
3 – Manual Crank Controls 6 – Overspeed Verification
