Appendix “A”

DP6H & DQ6H ENGINE MODELS

Clarke Engine Models

DP6H

DQ6H

Part Description

Part Number (standard items only, optional items not

shown)

Oil Filter

C04571

C04569

Fuel Filter (Primary)

C02736

Fuel Filter (Secondary)

N/A

Air Filter

C03749

C03244

Alternator

C072092

C072093

Fuel Injection Pump

C02911

C02912

Heat Exchanger

C051529

Starter Motor (12V)

N/A

Starter Motor (24V)

C072094

Switch, Oil Pressure

C07645 or C071884

Switch, Speed

C071571

Switch, Coolant Temperature

INCLUDED IN C071571 SPEED SWITCH or C071881

Thermistor

C071607 or C051749

Turbocharger

C061646

C061647

Thermostat

C051718

C051568

Nozzle, Injector

C0275324

C02754
