USING THE 12V BOOST FUNCTION
To operate BOOST, the charger must be connected to a 12V lead-acid
battery with the battery clamps connected. For optimal results, allow boost to
complete its 5-minute charge. After 300 seconds of boost the display will show
“000” and it should be possible to start the vehicle (whether FULL light is
illuminated or not). If unsuccessful when starting your vehicle, let the battery
rest for 15 minutes and try boost again. Most vehicles will start with one boost.
Do not use the boost function more than twice within a 24-hour period. If 2
boosts cannot successfully start your vehicle, have your battery replaced or
evaluated by a local battery supplier.
OPERATION
TO CHARGE THE BATTERY
1. Connect the charger to the battery (see page 7).
2. Connect the charger to the mains supply.
If the charger senses an incorrectly connected battery the error display will
indicate the fault as follows. The fault needs to be identified before you
continue connecting the battery.
ERROR CODES DISPLAYED
• E01: High temperature (with buzzer)
• E02: 1) Open Circuit (no load)
2) Dirty battery posts
3) Dead battery
4) Output short circuit
24V/7.5A 7.5A Blue
On
Press the VOLTAGE button to select
24V, then press the CURRENT button
repeatedly until 7.5A is shown.
This mode is recommended for 25-
200 AH batteries.
BOOST
12V/20A
FAS Red
On
On When connected to the battery, unit
can enter BOOST mode by pressing
the BOOST button. It takes 5 minutes
to charge.
MODE DISPLAY
POWER
LIGHT
BOOST
LIGHT
EXPLANATION
