CHECKING THE AIR FILTER
1. Remove the left side
maintenance panel.
2.
Remove the three air filter cover
screws shown on the right.
3. Slide out the air filter cover.
4. Remove the air filter element.
5. If the air filter is damaged contact
CLARKE spar
e parts department
for a replacement.
• If the filter is dirty, wash it in a
solu
tion of warm water and
mild detergent and rinse
thoroughly. Leave the filter to
dry completely, once it is dry
immerse the filter in clean engine oil and sqeeze the filter to remove
excess oil.
6. Replace the filter into its original position and rep
lace and secure the air
filter cover then replace the left side maintenance panel.
WARNING: DO NOT USE FLAMMABLE SOLVENTS OR PETROL TO CLEAN THE
AIR FILTER.
