Clarke JUMBO User Manual

- 2 -
TECHNICAL DATA
Model .......................................................................... JUMBO Motor ........................................................................... 230 VAC 50Hz 1ph Motor Rating ............................................................... 0.65 HP - 0.48kW Speed .......................................................................... 2850RPM Guaranted Sound Power Level ................................ 88dBL
WA
Maximum Air Pressure ................................................ 116 PSI - 8bar Air Displacement ........................................................ 3.5CFM Weight ......................................................................... 12kg (Packed) Duty Cycle .................................................................. S1* at 7bar Part Number ............................................................... 2310012 Dimensions (mm) ........................................................ 330x190x290 *Duty Cycle.....The Compressor may be used continuously
Please note that the details and specifications contained herein are correct at the time of going to
print. However CLARKE International reserve the right to change specifications at any time without
prior notice. Always consult the machines data plate
© Copyright CLARKE International, September 2003
-15-
PARTS LIST (Compressor)
No. Description Qty Part No.
1 Head Bolt 4 FN014002026 2 Head 1 FN116034010 3 Filter 1 FN317007000 4 Slotted Nut 1 FN116011065 5 Regulating Valve 1 FN347026000 6 Spring 1 FN112GE3501 7 Seal 1 FN047126001 8 Head Gasket 1 FN116011037 9 Valve Holder Plate 1 FN116034100
10 Cylinder Gasket 1 FN113113034 11 Cylinder 1 FN116034006 12 Screw 2 FN014011064 13 O-ring 1 FN010114000 14 Piston Ring Set 1 FN216011003 15 Piston 1 FN116011027 16 Gudgeon Pin 1 FN113113003 17 Circlip 2 FN015001000 18 Piston Assembly 1 FN416011027 19 Connecting Rod 1 FN116091021 20 Capacitor 1 FN009200014 21 Casing Cover 1 FN116032014 22 Oil Dipstick 1 FN012036000
23 Cover Gasket 1 FN116001025 24 Casing 1 FN116022065 25 Crankshaft 1 FN116034004 26 Bolt 2 FN116011038
27 Overload Cutout 1 FN008035000 28 Bearing 1 FN033018000 29 Rotor 1 FN031038000 30 Stator 1 FN463E35605 31 Bearing 1 FN033118000 32 Cover 1 FN116011050 33 Fan 1 FN116001003 34 Foot 4 FN116011006
35 Housing 1 FN163E01006 36 Wire Holder 1 FN029042000 37 Switch 1 FN008006000 38 Power Cable 1 FN112GE0300 39 Gasket Set 1 FN216GE0101 40 Spraygun 1 FN304013000 41 Rubber Hose 1 FN163E01005

Clarke JUMBO Specifications

General

Model	JUMBO
Power Supply	230V
Tank Capacity	50 Litres
Max Pressure	8 Bar
Air Displacement	210 l/min
Maximum Pressure	8 bar
Free Air Delivery	210 l/min
