Clarke PE16C50 User Manual

16 pages

To Next Page

To Next Page

Page #1 background image

Loading...

Page #1 background image

OPERATION & MAINTENANCE

INSTRUCTIONS

LS1216

Original Instructions

AIR COMPRESSOR

ELECTRIC MOTOR DRIVEN

Table of Contents

Other manuals for Clarke PE16C50

Operating & Maintenance Instructions16 pages

Questions and Answers:

A
Alex JenningsAug 20, 2025
Why Clarke PE16C50 Air Compressor will not start automatically?
- J
  Jason ClarkAug 20, 2025
  There are several reasons why your Clarke Air Compressor might not start automatically: * A blown fuse: Check the fuse rating and replace it if necessary. * A tripped starter overload: Reset it by depressing the button. * A defective pressure switch: Have an electrician change the pressure switch. * Fault in electrical installation: Let an electrician check electrical installation.
A
Angela RiosAug 22, 2025
Why does my Clarke PE16C50 run continuously and can’t attain the working pressure required?
- R
  Rebecca HartmanAug 22, 2025
  If your Clarke Air Compressor runs continuously without reaching the required working pressure, consider the following: * Blocked suction filter: Change the filter. * Slack V-belt: Tighten the V-belt. * Leak between compressor block and air receiver: Tighten the connection and repair the leak. * Suction rendered difficult or impossible at suction intake or the air being taken in is too warm: Ensure unobstructed airflow around the unit.
J
Joseph HunterAug 25, 2025
What to do if Clarke PE16C50 Air Compressor unit starts and stops more frequently than usual?
- D
  David RobertsAug 25, 2025
  If your Clarke Air Compressor starts and stops more frequently than usual, it could be due to: * Large amount of condensation in the air receiver: Drain off condensation at least once a week. * Leaks in the control unit or inspection cover: Locate leaks and repair them.
M
Megan FrankAug 27, 2025
Why does my Clarke Air Compressor unit start, but stop again after only a few revolutions?
- D
  David CastilloAug 27, 2025
  If your Clarke Air Compressor unit starts but stops after only a few revolutions, consider these causes: * Leaking non-return valve: Disconnect from the mains supply and empty air receiver. Clean or replace the non-return valve. * Blocked non-return valve: Thaw the non-return valve out. Ensure the unit is installed in a frost-free place.
A
Amanda JonesAug 28, 2025
What to do if Clarke PE16C50 Air Compressor becomes too hot?
- G
  Gabrielle HillAug 28, 2025
  If your Clarke air compressor becomes too hot, it could be due to: * Insufficient ventilation: Ensure sufficient air is supplied to the flywheel or fan and that hot air is properly vented. * Low oil level: Fill with oil. * Dirt on cooling fins or the suction filter: Clean the cooling fins and suction filter.
M
Mary WalkerAug 29, 2025
Why Clarke PE16C50 Air Compressor’s oil consumption rising?
- M
  Mrs. Brenda TaylorAug 30, 2025
  If your Clarke Air Compressor's oil consumption is rising, consider these potential causes: * Too much oil in the compressor: Check the oil level a few minutes after stopping. * Working temperature of compressor too high because of insufficient cooling: Increase ventilation to air compressor. * Intake air filter blocked: Clean or change the air filter. * Unit too small in proportion to air consumption: Connect supplementary. * Semi-automatic unit Load too small: Convert to fully automatic operation.
P
plevySep 1, 2025
Why is there oil in the air delivered by my Clarke Air Compressor?
- L
  Lisa PetersonSep 1, 2025
  If there is oil in the air delivered by your Clarke Air Compressor, it could be due to: * Sump over full: Reduce oil to the correct level. * Intake air filter blocked: Change the air filter.
C
coryevansSep 2, 2025
What to do if Clarke PE16C50 unit starts when no air is being used?
- D
  Daniel RobertsSep 2, 2025
  If your Clarke Air Compressor unit starts when no air is being used, it is likely due to leaks in the pipework system. Locate and repair any leaks.
J
Jacqueline RobinsonSep 4, 2025
How to fix unusual noise from Clarke Air Compressor?
- J
  jasonponceSep 4, 2025
  If you notice an unusual noise from your Clarke Air Compressor, check the following: * Loose bolts: Tighten the bolts. * V-Belt flywheel or cooling coil touching belt guard: Find the place of contact and remedy the fault. * Loose flywheel: Tighten the flywheel. * Unit installed on an unsuitable base: Move the unit to a more solid base.
E
Evan RodriguezSep 6, 2025
What to do if Clarke PE16C50 Air Compressor keep blowing fuses?
- A
  Allison AdamsSep 6, 2025
  If your Clarke Air Compressor keeps blowing fuses, it might be due to an inadequate size fuse installed. Replace it with the correct fuse, referring to the chart.

Clarke PE16C50 Specifications

General

Brand	Clarke
Model	PE16C50
Category	Air Compressor
Language	English

Summary

SAFETY PRECAUTIONS

General Safety Rules

Lists critical safety guidelines for operating the compressor.

INSTALLATION

Installation Guidelines

ELECTRICAL CONNECTIONS

SUGGESTED FUSE RATINGS

BEFORE STARTING COMPRESSOR, CHECK:-

Pre-Start Checks and Warnings

Details essential checks before starting and critical warnings for compressor operation.

TO START COMPRESSOR

Starting Procedure

TO STOP COMPRESSOR

Stopping Procedure

OUTLET PRESSURE ADJUSTMENTS

Portable Compressor Outlet Adjustment

OVERLOAD BUTTON (SINGLE PHASE ONLY)

TROUBLESHOOTING CHART

Troubleshooting Common Issues

Provides solutions for common compressor problems like not starting or faulty valves.

Troubleshooting Performance Issues

Addresses issues like stopping after a few revolutions, blowing fuses, and noise.

Troubleshooting Operational Issues

Covers continuous running, frequent starting/stopping, and no air delivery.

Troubleshooting Temperature and Oil Issues

Addresses overheating, oil in air delivery, and condensation problems.

TORQUE VALUES FOR CYLINDER HEAD BOLTS

Cylinder Head Bolt Torque Specifications

MAINTENANCE CHART

Scheduled Maintenance Tasks

Outlines daily, weekly, and 6-monthly maintenance checks and replacements.
