Clarke Raider 15/500 User Manual (English)

Questions and Answers:

M
Matthew LeeJul 30, 2025
What to do if my Clarke Air Compressor has stopped and does not start?
- M
  mwilliamsJul 31, 2025
  If your Clarke Air Compressor has stopped and won't start, there might be a few reasons. First, check the electrical connections, clean, and tighten them if needed. If that doesn't work, the overload cutout switch may have tripped; switch off the compressor, wait about 5 minutes, press the reset button, and switch it on again. If the problem persists, the motor windings might be burnt out, and you should contact your Clarke dealer for a replacement motor.
D
Devon QuinnAug 4, 2025
Why my Clarke Raider 15/500 Air Compressor does not start?
- M
  Mary SalazarAug 4, 2025
  If your Clarke Air Compressor doesn't start, it could be because the reservoir is already fully pressurized. To fix this, open the drain valve to release air. The compressor should start again once the pressure decreases.
D
Dylan MartinezAug 9, 2025
Why my Clarke Air Compressor does not reach the set pressure and overheats easily?
- A
  Amber RochaAug 9, 2025
  If your Clarke Air Compressor doesn't reach the set pressure and overheats easily, it might be because the compressor head gasket is blown, or a valve is broken. Return the machine to your nearest service agent for repair.
M
Mrs. Beth JonesAug 14, 2025
What to do if air is leaking from the non-return valve of my Clarke Raider 15/500 when it is not running?
- V
  victoria95Aug 14, 2025
  If air is leaking from the non-return valve of your Clarke Air Compressor when it's not running, it could be due to a faulty non-return valve. First, completely drain the air from the receiver. Then, remove the valve end plug, carefully clean the valve seat and the gasket, and reassemble everything.
K
Kevin MannAug 19, 2025
How to fix air pressure if the regulator will not adjust on my Clarke Raider 15/500?
- H
  hernandezrachelAug 19, 2025
  If the air pressure from the regulator on your Clarke Air Compressor won't adjust, the diaphragm within the regulator body might be broken. Replace the regulator to resolve this issue.
D
duane02Aug 25, 2025
What to do if my Clarke Air Compressor is very noisy and makes a metallic knocking sound?
- T
  Tammy SilvaAug 25, 2025
  If your Clarke Air Compressor is making metallic knocking sounds and is very noisy, the compressor is damaged and requires an overhaul. Return the machine to your nearest service agent.

Clarke Raider 15/500 Specifications

General

Brand	Clarke
Model	Raider 15/500
Category	Air Compressor
Language	English

Summary

Product Introduction

Product Guarantee

Details warranty period, conditions, and exclusions for the compressor.

Parts and Servicing Information

Contact details for ordering parts and arranging service.

Safety Precautions

General Safety Rules

Essential safety guidelines for operating the compressor to prevent injury and damage.

Electrical Connections

Mains Supply Connection

Instructions for safely connecting the compressor to a 230V mains power supply.

Assembly Instructions

Attach the Wheels

Step-by-step guide for attaching the wheels to the compressor unit.

Fit the Air Filter

Instructions for correctly installing the air filter assembly.

Attach Support Feet

Procedure for fitting the support feet to the compressor base.

Pre-Operation Procedures

Install Oil Filler Cap

Steps to install the oil filler cap after initial checks.

Safe Moving Instructions

Guidance on how to safely lift and move the air compressor.

Before Use Checks

Perform Pre-Operation Checks

Checklist of essential inspections before powering on the compressor.

Check and Fill Oil Level

Procedure for verifying and adding the correct type of compressor oil.

Operation Guide

Connect Air Tools

Instructions for attaching air hoses and tools to the compressor outlet.

Starting the Compressor

Steps to power on the compressor and its automatic pressure regulation.

Operational Checks and Adjustments

Test Safety Valve

How to perform a functional test on the safety valve.

Set Outlet Pressure

Guide to adjusting the output pressure using the pressure regulator.

Understanding Gauges

Explanation of the reservoir and outlet pressure gauges.

Operating Procedures

Disconnect Air Tools

Procedure for safely disconnecting tools from the air hose.

Turn Off Compressor

Steps for safely shutting down and depressurizing the compressor.

Maintenance and Care

Drain Reservoir Daily

Instructions for draining condensate from the reservoir after each day's use.

Thermal Overload Reset

How to reset the compressor's thermal overload protection.

Routine Maintenance

Monthly Air Filter Cleaning

Guide for cleaning the air filter monthly or more often in dusty conditions.

Periodic Checks and Specifications

Check Non-Return Valve

Procedure for checking the non-return valve for leaks every six months.

Technical Specifications

Key technical data including pressure, voltage, and dimensions.

Troubleshooting Guide

Common Issues and Solutions

Troubleshooting tips for common problems like starting issues, overheating, and pressure regulation.

Component Identification

Exploded Diagram

An illustrated breakdown showing the location of all compressor components.

Parts Listing

Parts Identification and Numbers

A comprehensive list of all parts with their corresponding part numbers for easy ordering.

Declaration of Conformity

Product Compliance Statement

Confirmation that the air compressor meets applicable EU directives and regulations.

Declaration of Conformity Details

Directive Compliance Details

Specific directives and standards the product complies with for market access.

Popular Accessories

A selection of recommended accessories to enhance compressor functionality.
