Clarke Ranger 7/240 User Manual (English)

Questions and Answers:

J
Jeanne SanchezJul 31, 2025
What to do if my Clarke Ranger 7/240 Air Compressor has stopped and does not start?
- J
  Jennifer GallegosJul 31, 2025
  If your Clarke Air Compressor has stopped and won't start, there might be a few reasons. First, check the electrical connections, clean, and tighten them if needed. If that doesn't work, the overload cutout switch may have tripped; switch off the compressor, wait about 5 minutes, press the reset button, and switch it on again. If the problem persists, the motor windings might be burnt out, and you should contact your Clarke dealer for a replacement motor.
G
ginawatkinsAug 5, 2025
Why my Clarke Air Compressor does not reach the set pressure and overheats easily?
- C
  Cameron LambertAug 6, 2025
  If your Clarke Air Compressor doesn't reach the set pressure and overheats easily, it might be because the compressor head gasket is blown, or a valve is broken. Return the machine to your nearest service agent for repair.
T
tonybergerAug 11, 2025
What to do if air is leaking from the non-return valve of my Clarke Ranger 7/240 when it is not running?
- J
  Jeffery StephensAug 11, 2025
  If air is leaking from the non-return valve of your Clarke Air Compressor when it's not running, it could be due to a faulty non-return valve. First, completely drain the air from the receiver. Then, remove the valve end plug, carefully clean the valve seat and the gasket, and reassemble everything.
J
Joshua MirandaAug 17, 2025
How to fix air pressure if the regulator will not adjust on my Clarke Air Compressor?
- H
  Heidi YatesAug 17, 2025
  If the air pressure from the regulator on your Clarke Air Compressor won't adjust, the diaphragm within the regulator body might be broken. Replace the regulator to resolve this issue.
E
Ellen TuckerAug 25, 2025
What to do if my Clarke Air Compressor is very noisy and makes a metallic knocking sound?
- A
  Ashley ClarkAug 25, 2025
  If your Clarke Air Compressor is making metallic knocking sounds and is very noisy, the compressor is damaged and requires an overhaul. Return the machine to your nearest service agent.

Clarke Ranger 7/240 Specifications

General

Motor Power	2.2 kW
Voltage	240 V
Air Displacement	7 CFM
Power Source	Electric
Tank Capacity	24 liters
Phase	Single

Summary

INTRODUCTION

GUARANTEE

Details the 12-month guarantee against faulty manufacture, conditions of invalidity, and return policy.

PARTS AND SERVICING

Provides contact details for obtaining parts and servicing the compressor.

SAFETY PRECAUTIONS

General Safety Rules

Lists 20 essential safety rules for operating the air compressor, covering air hazards, maintenance, and tool usage.

ELECTRICAL CONNECTIONS

Connecting to Mains Supply

Instructions for connecting the compressor to a 230V supply, plug requirements, and wiring colour codes.

ASSEMBLY

ATTACH THE WHEELS

Instructions and diagrams for attaching the wheels to the compressor using washers and nuts.

ATTACH THE SUPPORT FOOT

Guidance on inserting the support foot into its designated position on the compressor.

FIT THE AIR FILTER

Steps for removing the travel plug and screwing in the air filter hand-tight.

FIT THE OIL FILLER CAP

MOVING THE AIR COMPRESSOR

Cautionary advice on lifting and moving the compressor safely, emphasizing assistance and proper handling.

BEFORE USE

Pre-operation Checks

Checks before connecting to power: ON/OFF switch, level ground, and matching supply voltage.

CHECK THE OIL LEVEL

Instructions on checking the oil level via the sight glass and adding SAE30 oil if needed.

OPERATION

ATTACHING AIR TOOLS

Warning and steps for attaching air hoses and tools to the compressor's outlet valve.

TURNING THE COMPRESSOR ON

Procedure for plugging in and starting the compressor, noting its automatic shut-down and restart behaviour.

CHECK THE SAFETY VALVE

Safety Valve Operation Check

Instructions on testing the safety valve by pulling the ring and a warning not to adjust it.

SET THE OUTPUT PRESSURE

How to adjust the output pressure using the regulator on the left hand outlet valve.

GAUGES

Explanation of the reservoir pressure gauge and the outlet pressure gauge.

REMOVING TOOLS FROM THE AIR HOSE

Removing Tools

Steps to safely remove air tools, including setting the regulator to zero and depressurising the hose.

TURNING THE COMPRESSOR OFF

Procedure for turning off the compressor, disconnecting power, and depressurising the reservoir.

DRAINING THE RESERVOIR

Daily Reservoir Drainage

Instructions to drain condensate from the reservoir after each day's use and before storage.

RESET BUTTON

Thermal Overload Reset

Explanation of the thermal overload device and how to use the reset button if the motor cuts out.

MAINTENANCE

CLEAN THE AIR FILTER (MONTHLY)

Detailed steps for removing, cleaning (with water if needed), drying, and refitting the air filter.

CHECK THE NON-RETURN VALVE (EVERY 6 MONTHS)

Non-Return Valve Check

Procedure to check the non-return valve for leaks and replace parts if necessary.

SPECIFICATIONS

Technical Specifications

Lists key specifications including Max Pressure, Voltage, Air Displacement, Capacity, Fuse Rating, Dimensions, Sound Level, and Weight.

TROUBLESHOOTING

Troubleshooting Guide

A table addressing common problems like 'stopped and does not start' or 'overheats' with probable causes and remedies.

EXPLODED DIAGRAM

Exploded View Diagram

A detailed diagram showing all the parts of the compressor with numerical references.

PARTS LIST

Parts Identification

A comprehensive list of all compressor parts with their corresponding part numbers.

DECLARATION OF CONFORMITY - Part 1

Declaration of Conformity Details

States product details, model, date of issue, notified body, and noise conformity information.

DECLARATION OF CONFORMITY - Part 2

Compliance Directives and Standards

Lists applicable directives, standards, CE mark application date, and director's signature.

POPULAR ACCESSORIES

Recommended Accessories

Showcases popular accessories like air tool kits, sanders, and spray guns available for the compressor.

Air Hose Options

Details available air hose types, including black rubber and recoil hoses, with length information.

QUALITY PRODUCTS

Clarke Product Range Overview

Highlights various Clarke product categories like Air Compressors, Generators, Power Washers, Welders, and more.
