MIG 160TM
OPERATING & MAINTENANCE
INSTRUCTIONS
0108
Part No: 6015530

Questions and Answers

  • M
    Madeline RobertsAug 14, 2025
    Why does my Clarke Welding System cut out while I'm using it?
    • B
      Brittany MurphyAug 14, 2025
      If your Clarke Welding System cuts out during use, it's likely because you've exceeded the duty cycle, activating the auto cut-out. To resolve this, allow the welder to cool down for 10-30 minutes before resuming operation. Keep in mind that repeatedly exceeding the duty cycle can damage the welder, and it might indicate that the welder's output is insufficient for your specific application.
  • A
    Anna LeeAug 17, 2025
    Why are my welds poor quality with my Clarke Welding System?
    • A
      Andrea PetersAug 18, 2025
      Poor quality welds from your Clarke Welding System can stem from several causes: * Insufficient gas at the weld area. If draughts are present, relocate to a sheltered area or increase the gas supply. * An incorrect gas/wire combination. Consult the Mig Welding manual for guidance. * A workpiece that is rusty, painted, damp, oily, or greasy. Ensure the workpiece is clean and dry. * Wire that is rusty or dirty. Make sure the wire is clean and dry. * Poor earth contact. Check the connection between the ground clamp and the workpiece.
  • T
    Tanya ChristianAug 21, 2025
    Why is the wire feed erratic on my Clarke Welding System?
    • J
      Johnathan GarciaAug 21, 2025
      Erratic wire feed in your Clarke Welding System can be caused by: * A drum brake that is too light. Slightly loosen the drum brake. * A worn feed roller. Check the roller and replace if necessary. * Insufficient pressure on the feed roller. Increase the pressure, but avoid overtightening. * Wire that is dirty, rusty, damp, or bent. Re-cut the wire and ensure it is clean. * A partially blocked liner. Clear the liner with compressed air.
  • T
    Timothy MunozAug 25, 2025
    What to do if wire welds itself to tip on Clarke Welding System?
    • Y
      Yvonne JohnsonAug 25, 2025
      If the wire in your Clarke Welding System is welding itself to the tip, it could be due to: * Wire feed speed being too low. Unscrew the tip, cut the wire, and fit a new tip. Increase the wire speed before operating again. * Using the wrong size tip. Change to the correct tip size.
  • J
    Jeffrey AguilarAug 27, 2025
    Why does the wire feed into a bird's nest tangle on my Clarke Welding System?
    • J
      John RichardsonAug 27, 2025
      If the wire feeds into a bird's nest tangle with your Clarke Welding System, it's likely due to: * The wire being welded to the tip. Follow the steps above for 'Wire welds itself to tip' and reduce feed roller pressure, so the wire slips on the roller if a blockage occurs. * A damaged wire liner preventing smooth operation. Renew the wire liner.
  • M
    Melissa MannAug 31, 2025
    What to do if feed motor operates but wire will not feed in Clarke Welding System?
    • D
      danieladamsAug 31, 2025
      If the feed motor operates but the wire won't feed in your Clarke Welding System, it could be due to: * Insufficient feed roller pressure. Increase the roller pressure. * A burr on the end of the wire. Re-cut the wire square. * A blocked or damaged liner. Clear it with compressed air or replace the liner. * Inferior wire. Use only good, clean wire.
  • G
    gloriaschneiderSep 3, 2025
    Why are there tangled coils of wire around the drum of my Clarke Welding System?
    • J
      Joseph HuntSep 3, 2025
      If you're experiencing tangled coils of wire around the drum of your Clarke Welding System, it's likely because the drum brake is too slack. Tighten the drum brake, but be careful not to overtighten it.
  • R
    Randy YoungSep 6, 2025
    Why does wire jam in tip when welding aluminum with Clarke Welding System?
    • V
      Vanessa FlowersSep 6, 2025
      If the wire jams in the tip when welding aluminum with your Clarke Welding System, it's likely because the tip is too small. Use a slightly oversized tip; for example, use a 1mm tip for 0.8mm wire. This applies to aluminum only.
  • C
    Crystal MaxwellSep 9, 2025
    How to fix a Clarke Welding System with no life?
    • M
      Melissa CrawfordSep 9, 2025
      If your Clarke welder has no life, replace the fuses as necessary. If the problem persists, return the welder to your local dealer. Also, check the fuse size.

Summary

Welder Specifications

Power Data

Details of primary input and secondary output power ratings for the welder.

Wire and Gas Specifications

Information on usable wire sizes and recommended gases for different welding applications.

Duty Cycle

Explanation of the welder's duty cycle expressed as a percentage of time for welding current.

Parts and Service Contacts

Guarantee

Electromagnetic Interference (EMC)

Assessment of Area

Evaluating the environment for potential electromagnetic disturbances during operation.

Methods of Reducing Emissions

Techniques to minimize electromagnetic interference generated by the welding equipment.

Safety Precautions

General Precautions

Essential safety measures for operating welding equipment, covering personal protection and environmental factors.

Fire and Explosion Prevention

Electric Arc Welding Safety

Burn and Personnel Protection

Specific safety measures for electric arc welding, including burn and nearby personnel protection.

Electrical Safety and Shock Prevention

Shock Prevention and Earthing

Critical safety guidelines to prevent electric shock hazards and proper earthing procedures.

Preparation of the Working Area

Additional Safety Precautions for MIG Welding

MIG Welding Warnings and Prohibitions

Safety Equipment

MIG Welding Principles of Operation

Electrical Connections

Assembly

Handle and Wheels

Step-by-step guide for assembling the handle and wheels onto the welding machine.

Face Shield Assembly

Gas Supply Setup

Preparation for Use

Installing the Welding Wire

Steps for correctly loading and preparing the welding wire spool for operation.

Selecting the Correct Drive Roller Groove

Operation

Tuning The Welder

Guidance on adjusting wire feed speed and voltage for optimal welding performance.

Wire Size Specification Chart

Welding Tips and Maintenance

Trouble Shooting

Parts Diagram

Torch Assembly

Wiring Diagram

Clarke MIG 160TM Specifications

General IconGeneral
Input Voltage230V
Welding Output Current30A - 160A
Wire Diameter0.6mm - 0.8mm
CoolingFan cooled
Wire Size Range0.6mm - 0.8mm
