ELECTRICAL CONNECTIONS
See wiring lable on the power cable.
SUGGESTED FUSE RATINGS
LUBRICATION
Pump: Use Clarke compressor oil, as indicated on machine plate.
MOTOR SIZE SINGLE PHASE
MOTOR D.O.L.
THREE PHASE MOTORS 415V
KW HP DOL STAR DELTA
0.75 1.0 13 amp 10 amp
1.1 1.5 13/15 amp 10 amp
1.5 2.0 20 amp 10 amp
1.9 2.5 20 amp
2.2 3.0 30 amp 16 amp
3.0 4.0 40 amp 20 amp
4.0 5.5 50 amp 25 amp
5.5 7.5 30 amp
7.5 10.0 25 amp
