-7-
Parts List
1 Engine 1501 Honda 7999010 7999020 1
2 Pump 21652 21653 1
3 Frame 1321910 8820027 1
3a Wheel 1801 (not shown) N/A 2100303 2
3b Clip RDF 25 1801 (not shown) N/A 2100304 2
4 Cover 1982311 1982311 1
9 Drive Key 881090 881090 1
13 Foot 1321920 N/A 4
13a Nut 380242 N/A 4
14 Hose Connection 1270940 1270940 1
15 Detergent Hose 1262790 1262790 1
16 Detergent Filter 1341030 1341030 1
16a Detergent Hose assembly 1269115 1269115 1
17 Data Plate 5885??? 5885??? 1
18 Pressure Hose 7310170 7310170 1
19 Gun 7310771 7310771 1
20 Lance 7310774 N/A 1
21 Lance (Not Shown) N/A 7310775 1
22 Bracket 1982300 1982300 1
No Description Part Number
Tiger1501 Tiger1801 Qty
PARTS & SERVICE TEL: 020 8988 7400
or e-mail as follows:
PARTS: Parts@clarkeinternational.com
SERVICE: Service@clarkeinternational.com
