ELECTRICAL CONNECTIONS
IMPORTANT - SINGLE PHASE MACHINES ONLY
The wires in the mains lead of this machine are coloured in accordance with the
following code:
Green and Yellow – Earth
Blue – Neutral
Brown – Live
As the colours of the wires in the lead of this appliance may not correspond with
the coloured markings identifying the terminals in your plug, proceed as follows.
• The wire which is coloured green and yellow must be connected to the
terminal which is marked with the letter E or by the earth Symbol ( ) or
coloured green or green and yellow.
• The wire which is coloured blue must be connected to the terminal which is
marked with the letter N or coloured black.
• The wire which is coloured brown must be connected to the terminal which is
marked with the letter L or coloured red.
WARNING: This machine must be earthed.
110V Model
Connect the mains lead to a suitable 110V (50Hz) electrical supply through
anapproved plug or a suitably fused isolator switch. If using a portable 110V
transformer,make sure it has a rated capacity sufficient to take the load of the
air compressor.
If in any doubt, consult a qualified electriction.
5
