Clarke Woodworker CBS12WV User Manual

2 Wheel HT14600203
3 Hex Nut HT270100312
7 Mitre Shaft HT2601008112
11 Knob Screw HT14601101
12 Switch Box HT14601201
13 Machine Screw HT2651011112
15 Switch Cover HT14601501
16 Mitre Shaft HT2601057112
17 Knob Screw HT14601701
18 Hex. Screw HT2611105112
21 Screw HT775515
22 Guide Holder HT14602201
23 Blade Guard HT14602301
24 Ball Bearing HT280120635
25 Mitre Shaft HT2621013112
26 Hex. Nut HT270100312
28 Motor HT12056
29 Motor Cover HT14602901
30 Self-Tap Screw HT845519
31 Spring Seat HT14603101
33 Drive Gear HT14603301
34 Shaft HT14603401
35 Screw HT14603501
36 Washer HT2920073
37 C. S. Washer HT14603702
38 Set Screw HT2621031112
39 Washer HT254201322
40 Machine Screw HT2651104112
41 Spiral Spring HT14604101
42 Set Screw HT2621017112
43 Table Tilt Truss HT14604301
44 Square Nut HT397606
45 Machine Screw HT2641017112
46 Self-Tap Screw HT8453512
47 Speed Switch HT14604701
48 Machine Screw HT2651108112
50 Timing Belt HT301204
51 Hex. Nut HT270100412
53 Hex. Head Bolt HT2601023112
54 Drive Wheel HT14605402
55 Screw HT1460550
No. Description Part No. No. Description Part No.
14
56 Front Cover HT14605601
57 Wheel Body HT14605601
58 Machine Screw HT2651047112
60 Angle Pointer HT14302401
61 Machine Screw HT2651010113
62 Insert Plate HT14606201
63 Table HT14606301
67 Base HT14606701
68 Electronic Switch HT286007
69 Wheel Support HT14606902
70 Saw Blade 6470031
71 Micro-Switch HT3013020
77 Machine Screw HT2641005112
78 Mitre Gauge HT14607801
79 Angle Pointer HT14302401
81 Machine Screw HT2651010113
83 Knob Screw HT14608301
85 Guide Bar HT14608502
86 Clamp HT10308202
89 Machine screw HT818850320
90 Hex Nut HT617003
92 Wire HT278035
95 Nameplate HT14609502
97 Nameplate HT14609701
98 Nameplate HT14609802
99 Knob HT301305
103 Machine Screw HT81885412
104 Earthplate HT30013
105 Washer HT958504
106 Spring Washer HT937604
107 I.G.Washer HT861760
108 Guide Holder HT300902
109 Washer HT300303
110 Hex. Nut HT617006
111 Washer HT958508
112 C. S. Washer HT89418606
113 Ball Bearing HT80029
114 H. S. Washer HT89318626
115 C. S. Washer HT89418609
116 Rubber Tyres HT300505
117 Motor Brush Set see dealer
Spare Parts List

Clarke Woodworker CBS12WV Specifications

General

Brand	Clarke
Model	Woodworker CBS12WV
Category	Saw
Language	English
