Electrical Connections
WARNING! THIS APPLIANCE MUST BE EARTHED
IMPORTANT: The wires in the mains lead are coloured in accordance with the following
code:
Green & Yellow - Earth
Blue - Neutral
Brown - Live
As the colours of the flexible cord of this appliance may not correspond with the coloured
markings identifying terminals in your plug proceed as follows:
• Connect GREEN & YELLOW coloured cord to plug terminal marked with a letter E or
Earth symbol “ ” or coloured GREEN or GREEN & YELLOW.
• Connect BROWN coloured cord to plug terminal marked with a letter L or coloured RED
• Connect BLUE coloured cord to plug terminal marked with a letter N or coloured BLACK
IMPORTANT! If this appliance is fitted with a plug which is moulded onto the electric cable
(i.e. non- re-wireable) please note:
1. The plug must be thrown away if it is cut from the electric cable. There is a danger
of electric shock if it is subsequently inserted into a socket outlet.
2. Never use the plug without the fuse cover fitted.
3. Should you wish to replace a detachable fuse carrier, ensure that the correct
replacement is used (as indicated by marking or colour code).
4. Replacement fuse covers can be obtained from your local dealer or most electrical
stockists.
Fuse Rating
The fuse in the plug must be replaced with one of the same rating (13 amps) and this
replacement must be ASTA approved to BS1362.
Assembly and Installation
Upon unpacking the contents of the carton you will note that some assembly work is
necessary before the Bandsaw can be Installed. The Feet (12, Fig.1) and the Table Assembly
must be fitted before the Bandsaw may be attached to a suitable workbench.
WARNING! Disconnect the bandsaw from the mains supply before
removing the front cover.
Note: The bandsaw is provided with a microswitch to prevent the saw from operating if the
cover is left open or is opened whilst the saw is running. If the saw does not operate when
the cover is replaced it may be because the microswitch is not closed. Check that the
microswitch will operate when replacing the cover.
5
