Clarson PUBLIC III CE - Mounting Material and Component Positioning; Mounting Material for Components; Microphone Installation; Loudspeaker Installation

4 5
2x O
F
2x C
2x C
H
N
Service and Installaon Instrucons
German
English
Mounng material for microphone ceiling xaon:
drilling template
2 counter-sunk screws 3,5x30mm + 2 wall plugs 5x25mm
Mounng material for central unit:
4 screws 3,5x35mm, 4 wall plugs 5x25mm
4 screws 3,5x16mm
2 hook-and-loop fasteners
(4)
Mounng material for loudspeaker:
4 screws 3,5x35mm, 4 wall plugs 5x25mm
2 screws 2,9x16mm, 2 decorave caps
cable es 100mm
Mounng material for power supply:
hook-and-loop fastener
(4)
.
35.054.011
35.054.012
35.054.006
40.054.844
40.054.827
40.054.829
40.054.830
40.054.827
40.054.831
40.054.832
40.054.830
O
Delivery Contents Mounng Material
Posioning of the Components Microphone, Loudspeaker and Intercom Console
Loudspeaker:
- the loudspeaker must not be installed in the hatched area (pos. 1) to avoid interferences
- preferably the loudspeaker has to be installed on the wall
- installaon height >2m
- avoid loudspeaker radiaon towards the control room door
- distance microphone / loudspeaker >2m
the greater the distance, the beer the transmission quality
Intercom Console:
- the intercom console has to be placed as far from the control room door
as possible
Maximum speech distance to the microphone: 10 cm
Microphone:
- ceiling xaon
- as close to the user´s working posion as possible
- avoid collision with other components suspended from the ceiling
6 5
3 8
5
J
Pos. A Wall xaon of the loudspeaker
Pos. B Ceiling xaon of the loudspeaker
Pos. 1 Prohibited xaon area for the loudspeaker
Pos. 2 Wall xaon of the microphone
Pos. 3 Privileged xaon area of the loudspeaker
Pos. 4 Oponal xaon area of the loudspeaker
Pos. 5 Intercom console in the control room
>
2
m
1)
3)
4)
1)
1)
2)
4) 3)
>
2
m
2)
>
2
m
1)
3)
4)
1)
1)
2)
4) 3)
>
2
m
2)
5)
5)
5)
5)
B
A
B
A
