-7-
30 dB (Orange,Gray,Orange,Black,Brown) 3830F
32 dB (Green,Brown,Brown,Black,Brown) 5110F
34 dB (Purple,Blue,Gray,Black,Brown) 7680F
36 dB (Brown,Brown,Green,Brown,Brown) 1151F
38 dB (Brown,White,Blue,Brown,Brown) 1961F
40 dB (Yellow,Red,Red,Brown,Brown) 4221F
Silver solder is provided in the kit for this purpose. THE RESISTOR KIT IS FOR SETTING THE MC
GAIN WHICH WILL OPTIMIZE LEVELS, NOISE, AND EFFICIENCIES OF LESS TYPICAL MC
CARTRIDGES.
5) Having completed the resistor changes, replace the top cover.
BALANCED, TAPE, HIGH LEVEL INPUT INFORMATION
The BALANCED INPUT is a true differential high level input, wired as follows:
PIN 1: GROUND
PIN 2: POSITIVE (NON-INVERTED) SIGNAL
PIN 3: NEGATIVE (INVERTED) SIGNAL
It may be used with CD players that have a balance output, or any other high level, balanced
source. The TAPE IN of the 6/6L should be connected to the LINE OUT or TAPE OUT of the tape
deck. The TAPE input does not appear on the selector switch. It is activated by the TAPE switch. (See
FRONT PANEL CONTROLS: TAPE SWITCH.)
