-8-
OUTPUTS
The 6/6L has both regular (single-ended) and balanced outputs. Both are working at all times,
and may be used separately, or simultaneously.
TAPE OUTPUT
Whatever input is selected by the INPUT SELECTOR will be fed to the TAPE OUTPUT jacks.
This should be connected to the TAPE IN or LINE IN of the tape deck.
REGULAR OUTPUTS
Simply connect your regular interconnects to the RCA output jacks marked REGULAR MAIN
OUT on the back of the 6/6L.
BALANCED OUTPUTS
A balanced power amplifier and balanced interconnects are also required. For use with balanced
power amplifiers other than Classé, the wiring of the 3-pin XLR connectors must be wired as follows:
PIN 1: GROUND
PIN 2: POSITIVE (NON-INVERTED) SIGNAL
PIN 3: NEGATIVE (INVERTED) SIGNAL
If the pin configuration of the power amplifier differs from above, the balanced interconnects
must be modified to accommodate the different power amp.
Having confirmed the correct connections, plug the XLR connectors of the balanced
interconnects into the locking XLR connectors on the rear panel of the 6/6L marked BALANCED
MAIN OUT. (To remove the connectors, press the tab above the connector.)
