ClassicFlame 34HF600GRA - Wall Mounting Bracket Installation; Hanging the Fireplace

2. Choose a wall location to attach the mounting
bracket (A). Position the mounting bracket (A)
in the desired location. Use a level to align the
bracket and mark the four holes with a pencil
(Fig. 2).
3. Drill 4 holes (∮5/16 in) in the wall. Insert
the wall anchors (BB) into the holes using a
hammer. (Fig. 3)
Fig. 2
Fig. 4
Wall Plug
0.3 in. x 1.5 in.
x 4
Hardware Used
BB
BB
AA
Fig. 3
x 4
Screw
0.2 in. x 1.5 in.
Hardware Used
AA
Fig. 5
B
A
5. Hang the replace (B) on the hooks at bottom
and push the replace (B) into mounting
bracket (A). Re-fasten the two screws
removed in Step 1.(Fig. 5)
7
4. Attach the mounting bracket (A) to the wall
fastening the 4 screws (AA) into the wall
anchors (Fig. 4).
x 2
Screw
0.2 in. x 0.31 in.
Hardware Used
