ClassicFlame 34HF600GRA - STAND BASE INSTALLATION INSTRUCTIONS

STAND BASE INSTALLATION INSTRUCTIONS
1. Use 4 screws to fasten the base bracket (C) to
the base (D.) (Fig. 6).
Fig. 6
C
D
x 4
Screw
1/4 in. x 0.7 in.
CC
8
Hardware Used
Fig. 7
2. Mount the replace to the base by hooking the
clips into position (Fig.7).
3. Fasten the base bracket to the replace with the
provided screw (Fig 8).
Fig. 8
x 1
Screw
1/4 in. x 0.5 in.
DD
Hardware Used
