ClassicFlame 36EB110-GRT - Mount the unit

E-6
Figure 4: Mounting Tab Location
Figure 5: Wall and Mounting Tabs
SECTION 4: MOUNTING
Install Method：
1.) Remove front frame (see figure 2).
2.) Remove the screws holding side panels and then remove the side panels (see figure 4 & 5).
3.) Insert the builders box into the opening in the framing.
36EB111-GRC
36EB221-GRC
36EB110-GRT
36EB220-GRT
36EB110-GRT
36EB220-GRT
36EB111-GRC
36EB221-GRC
