Clay Paky MYTHOS - Gobo Rotation

36
MYTHOS
C
hannel Mode
DMX
Value
Function
Standard Vector
A
NIMATION DISK INSERTION
0
- 255 Linear Animation Disk Insertion
ANIMATION DISK ROTATION
0
- 124
Continuous animation disk clockwise rotation at linearly variable speed
from fast (120 rpm) to slow (4.4 rph)
125 - 130 Stop rotation
131 - 255
Continuous animation disk counter-clockwise rotation at linearly
variable speed from slow (4.4 rph) to fast (120 rpm)
ROTATING GOBO SELECT
0 - 18 Empty position
19 - 37 Gobo 1
38 - 56 Gobo 2
57 - 74 Gobo 3
75 - 92 Gobo 4
93 - 111 Gobo 5
112 - 129 Gobo 6
130 - 150 Gobo 1 shakes at variable speed from slow (xx bpm) to fast (xx bpm)
151 - 171 Gobo 2 shakes at variable speed from slow (xx bpm) to fast (xx bpm)
172 - 192 Gobo 3 shakes …
193 - 213 Gobo 4 shakes …
214 - 234 Gobo 5 shakes …
235 - 255 Gobo 6 shakes …
GOB
O
CHANG
E
effect disabled if BEAM MODE is workin
g
GOBO ROTATION
0 - 21 Gobo indexing: 0° to 90° range
21 - 42 Gobo indexing: 90° to 180° range
42 - 63 Gobo indexing: 180° to 270° range
63 - 84 Gobo indexing: 270° to 360° range
84 - 105 Gobo indexing: 360° to 450° range
105 - 127 Gobo indexing: 450° to 540° range
128 - 190
Continuous gobo rotation at linearly variable speed from fast (180 rpm)
to slow (2.2 rph)
191 - 192 Stop rotation
193 - 255
Continuous gobo rotation at linearly variable speed from slow (2.2 rpm)
to fast (180 rpm)
ROTATING GOB
O
effect disabled if BEAM MODE is workin
g
FINE GOBO ROTATION
0 - 255 Fine Gobo Indexing
PRISM INSERTION
0 - 10 Prism out
11 - 132 Prism 1 into the light beam
133 - 255 Prism 2 into the light beam
PRIS
M
effect disabled if BEAM MODE is workin
g
