4
VOLERO WAVE
3
4
2
3
4
2
1
3
Projector installation - Fig. 3
The projector can be installed on the floor resting on specific rubber feet, on a truss, on the ceiling or wall.
WARNING: the safety chain must be installed except when the projector rests on the floor. (Code 105041-003 available upon request).
This must be secured to the projector support structure and then hooked to the two fastening points.
3.2 Installing the fixture
