Back plate assembly • Inside view
6 7
2
4 4
1. Hinged back plate
2. Orange metering tips
3. Dual injector
4. Suction lines
5. Quick change pump
6. Flow control valve
(includes black knob)
7. Air regulator
8. Air pressure gauge
9. Check valves
10. In-line strainer
11. Suction line valve
Product components
Before you begin, get to know the Athena
®
Reset Foamer components that you will need to use,
adjust or assemble.
