Safety, Operation and Maintenance Manual for Falcon (RA 530 B); Version 1.0
7
BEFORE USING THE AUTO-SCRUBBER (cont.)
PREPARATIONS FOR WORK
Depending on the type of operation the machine must be equipped respectively with the correct brushes
or pad-holders and pads.
• Place squeegee (E1) into the holder.
• Fix squeegee with the two star handle
screws (E2).
• Connect hose from the squeegee to the
waste water tank cover.
• Lower the squeegee with lever (A10).
• Fill the clean solution tank with water and
the cleaning agent required for the specific
task (Dilution rates will be on the label of the
cleaning solution). The maximum capacity of
the clean solution tank is 12 gal. (45 liters).
• Set the solution flow rate with the knob (C1)
(recommended position 1-2)
FUNCTIONAL PARTS AND ACCESSORIES
A. General view
1. Controls
2. Handle
3. Dome
4. Guide wheel
5. Solution flow regulating valve
6. Brush assembly side roller
7. Squeegee assembly
8. Disc brushes
9. Cylindrical brush
10. Lever to raise/lower squeegee assembly
11. Recovery tank
12. Solution tank bladder
13. Drain hose for recovery tank
14. Brush operation lever
B. Controls
1. Key switch
2. Operating LED
3. Low battery signal
4. Vacuum push button
5. Brush push button
6. Solution push button
C. Adjustments and connectors
1. Solution flow valve
2. Quick disconnect for external
solution hose
3. Cylindrical brush access plate
D. Brushes
1. Disc brushes
2. Cylindrical brush
E. Rear view
1. Squeegee assembly
2. Knob for fixation of squeegee
3. Angle adjustment for squeegee
assembly
4. Foot lever for raising brushes
5. Battery container
7. Solution bladder drain hose
F. Front view
1. Brush pressure adjustment
2. Supporting bar / Kick stand
G. Access to battery/component
compartment
