Technical Guide | HelixNet IP Network Guidance Page 3
HelixNet
“Network”
Digital
Partyline
In Figure 1 (below) teams in separate studios (A and B) can communicate with an
outside broadcasting truck on the same digital partyline system over their existing IP
network. With cabling integration possibilities in either XLR or CAT5/6, HelixNet
becomes a flexible solution in multiple scenarios.
- Live Production
- Performing Arts and Theatre
- House of Worship
- Theme Park Ride Communications (Figure 2)
Figure 1
Because of its IP capability, HelixNet is an excellent solution for intercom
communication for Theme Park Rides as shown in Figure 2 (below). A Park’s Network
Operations Center houses sets of HelixNet Main Stations per ride – one HMS is live
production, the second is a redundant back up. The HMS connects to a local switch, the
local switch then connects via CAT5/6 to a second PoE switch at the ride locale. HelixNet
endpoints (HKB and HXII-BP) are placed at strategic positions within the ride to connect
operators and provide a safe experience for the customer.
