ClearCom FOR-22 - Bill of Materials for FOR-22 Module PCB

FOR-22 4-WIRE INTERFACE
3-2
BILL OF MATERIALS FOR FOR-22 MODULE PCB
Component Part Component Description Qty Designator
151118 33PF 50V 5% NPO SMD 0805 12 C103,C105,C107,C110,C115,
C119,C203,C205,C207,C210,
C215,C219
151172 .1UF 50V 10% X7R SMD 0805 12 C104,C106,C111,C114,C117,
C118,C204,C206,C211,C214,
C217,C218
151176 .22UF 50V 10% X7R SMD 1210 6 C101,C102,C109,C201,C202,
C209
151200 22UF ALU 50V 20% SMD 8X6MM 2 C113,C112
170318 FOR-22 MAIN SMT PCB FAB 1
210174 EURO CARD RT ANG CONN 64
PIN M
1 J1
210226 JUMP JACK .1IN WITH HANDLE 2 JP100,JP200
210230 7 PIN DUAL ROW SOCKET
SPECIAL
1 J2
210273 DUAL ROW HEADER 3 POS
.230IN
2 JP200,JP100
240058 PIHER TRIMPOT SHAFT #5116
BLAC
4 P101,P102,P201,P202
280255 RIVET AVDEL #1189-2510 2 J1(2)
390029 T1 RT ANG PC MTG 5mA AMBER
LED
2 LED101,LED201
411197 10.0 1/10W 1% SMD 0805 4 R110,R122,R123,R210
411269 56.2 1/10W 1% SMD 0805 4 R118,R119,R218,R219
411285 82.5 1/10W 1% SMD 0805 2 R125,R225
411293 100 1/10W 1% SMD 0805 2 R115,R215
411310 150 1/10W 1% SMD 0805 2 R229,R129
411326 221 1/10W 1% SMD 0805 2 R109,R209
411389 1.00K 1/10W 1% SMD 0805 2 R130,R230
411431 2.74K 1/10W 1% SMD 0805 2 R208,R108
411454 4.75K 1/10W 1% SMD 0805 6 R120,R121,R124,R220,R221,
R224
411485 10.0K 1/10W 1% SMD 0805 18 R105,R106,R114,R116,R117,
R126,R127,R131,R132,R205,
R206,R214,R216,R217,R226,
R227,R231,R232
411527 27.4K 1/10W 1% SMD 0805 8 R101,R102,R103,R104,R201,
R202,R203,R204
411550 47.5K 1/10W 1% SMD 0805 2 R228,R128
450006 SPDT 12V MINI PC RELAY
ITT#SZ1
2 RL101,RL201
470059 50K TRIMPOT PIHER#PT10WH-
50K
4 P101,P102,P201,P202
481019 BAV70 DUAL DIODE COMMON
CATHOD
2 D201,D101
481020 BAW56 DUAL DIODE COMMON
ANODE.
4 D103,D104,D203,D204
481023 833 DUAL OPAMP... SOIC8 6 IC101,IC102,IC104,IC201,
IC202,IC204
481026 PMBT2222A NPN 40V 600MA
SOT-23
4 Q101,Q103,Q201,Q203
481032 M0C211 OPTOCOUPLER... S0IC8 2 IC203,IC103
