FOR-22 4-WIRE INTERFACE
3-5
BILL OF MATERIALS FOR FOR-22 LEVEL DETECT PCB
Part Number Component Description Qty Per Designator
151172 .1UF 50V 10% X7R SMD 0805 4 C5,C6,C7,C8
151176 .22UF 50V 10% X7R SMD 1210 2 C4,C2
151184 .47UF TAN 35V 10% SMT A 2 C1,C3
170317 FOR-22 LED SMT PCB FAB 1
210282 DUAL ROW HEADER 7 POS. .320IN 1 P1
390032 BI-COLOR RED/GREEN 3 LEAD 2 LED2,LED1
411358 475 1/10W 1% SMD 0805 2 R9,R8
411521 23.7K 1/10W 1% SMD 0805 2 R2,R5
411550 47.5K 1/10W 1% SMD 0805 3 R1,R4,R7
411631 332K 1/10W 1% SMD 0805 2 R3,R6
470050 100K TRIM POT V.ADJ PIHER#10V1 2 VR2,VR1
481023 833 DUAL OPAMP... SOIC8 1 IC1
481033 BAV99 DUAL DIODE... SOT23 8 D1,D2,D3,D4,D5,D6,D7,D8
481042 358 DUAL OPAMP GROUND
SENSING.
2 IC2,IC3
