Cleco 48EA Series - Page 27

Page 27
PL12EN-48EA
08/06/2015
EN
Description
1 503405 1 2 Retaining Ring
2 542536 1 2 Thrust Washer
3 1012614 2 4 O-Ring
4 22598 2 4 O-Ring
5 510675 1 2 Thrust Washer
6 800201 1 2 Retaining Ring
7 502981 1 2 Thrust Washer
8 541044 1 2 Pinion Adapter
9 541479 1 2 Extension Pinion
10 30923 1 3 O-Ring
11 542337 1 2 Washer
12 541008 1 Ring Gear
13 203749 6 12 Needle Bearing
14 541477 3 6 Planet Gear (20T)
15 Table "I" 1 Planet Carrier
16 541480 3 6 Planet Pin
17 Table "I" 3 6 Planet Gear
18 542473 1 Cover
19 Table "I" 1 Planet Cage
20 541438 1 Ring Gear Adapter
21 510754 3 6 Planet Pin
22 542474 3 6 Planet Gear (16T)
23 541436 1 Planet Cage
24 542471 1 Gear Case (includes Ref. 25 - 26)
25 800168 1 3 Needle Bearing
26 B124Z 1 2 Socket Head Cap Screw - #6-32 x 1/4
(#) Quantity
(X) Recommended Spare Parts (quantity shown based on 1-5 tools in operation)
(T) Teeth
Illustration "I": Double Stage Gearing Assembly
Ref Number # X
Cleco
®
Triple Stage Gearing
Table "I"
Ref. Description # 48EA(E)175 # 48EA(E)230
15 Planet Carrier 1 542327 1 542331
17 Planet Gear 3 541472 (14T) 3 541473 (17T)
19 Planet Cage 1 542531 1 542478
(T) Teeth
