Cleco 48EA Series - Page 30

Page 30
PL12EN-48EA
08/06/2015
“L”
3/8” Square Drive - 301676 (Pin Retainer)
3/8” Square Drive - 301677 (Ball Retainer)
1
See Service Notes
7
Cleco
®
Angle Head Attachment (Code AL3)
Model
48EA(E)15(---)
N
NOTE: Always replace the Bevel Gear
and Bevel Pinion at the same time
since they should wear equally.
1
2
3
4
5
6
16
7
5
8
18
17
19
3/8” 3/8”
11
10
9
13
14
15
12
N
N
7
7
1
1
301677
Ball Retainer
301676
Pin Retainer
Loctite
®
242/243
Loctite
®
242/243
