Cleco 48EA Series - Page 29

Page 29
PL12EN-48EA
08/06/2015
EN
Description
1 541206 1 Bracket (includes Ref. 2-3)
2 B132Z 2 4 Set Screw - #8-32 x 1/2
3 B129J 1 2 Set Screw - #8-32 x 5/16
4 541207 1 Splined Key
5 541169 1 Cover
6 207352 1 Retaining Nut
(#) Quantity
(X) Recommended Spare Parts (quantity shown based on 1-5 tools in operation)
Illustration "J": Reaction Bar Installation
Ref Number # X
Cleco
®
Reaction Bar Installation
EN
Description
1 531297 1 Bucking Bar Collar (includes Ref. 2-6)
2 B156A 1 2 Socket Head Screw
3 25285 1 2 Washer
4 B110D 1 3 Set Screw
5 531281 2 2 Locking Sleeve
6 C108Y 1 3 Nut
7 542473 1 Cover
8 207354 1 Retaining Nut
(#) Quantity
(X) Recommended Spare Parts (quantity shown based on 1-5 tools in operation)
Illustration "K": Reaction Bar Installation
Ref Number # X
