Cleco 48EA Series - Page 43

Page 43
PL12EN-48EA
08/06/2015
EN
Description
1 515539 1 Split Ring (includes Ref. 2)
2 526483 1 3 Rubber Band
3 502983 1 2 Thrust Washer
4 847596 1 3 Thrust Bearing
5 523945 2 4 Needle Bearing
6 513253 1 Angle Housing (includes Ref. 7)
7 500510 1 2 Needle Bearing
8 512553 1 2 Thrust Washer
9 513002 1 3 Retaining Ring
10 1013571 1 3 Thrust Bearing
11 500507 1 3 Needle Bearing
12 514883 1 3 Seal
13 503404 1 2 Retaining Ring
14 207354 1 Lock Nut
15 542472 1 1 Splined Adapter
16 513235 1 2 Thrust Washer
17 523946 1 Bearing Spacer
18 526728 1 1 Bevel Pinion
19 513244 1 1 Bevel Gear
20 513245 1 Retaining Nut
21 513230 1 2 Thrust Washer
22 513219 1 Output Spindle - 3/4" (includes Ref. 23-25)
23 23355 1 3 Button
24 9D6481 1 3 Spring
25 207766PT 1 3 Plug
26 543420 1 Output Spindle - 3/4" (includes Ref. 27-29)
27 1005005 1 3 Steel Ball
28 WS-750 1 3 Spring
29 LB-751 1 3 Bushing
(#) Quantity
(X) Recommended Spare Parts (quantity shown based on 1-5 tools in operation)
Illustration "R": 301839 AX6 Attachment (3/4” Square Drive)
301840 AX6 Attachment (3/4” Square Drive)
Ref Number # X
Cleco
®
Angle Head Attachment (Code AX6)
