Service Notes
Ft-Lbs
(in-lbs)
Nm
3 (10-14) 1.1-1.6
16 25-30 34-41
19 35-40 47-54
21 15-18 20-25
1 (4-6) 0.45-0.68
3 (4-6) 0.45-0.68
9 (4-6) 0.45-0.68
10 60-65 81-88
H 16 15-20 20-27
I 26 (10-14) 1.1-1.6
J 6 40-50 54-68
K 8 40-50 54-68
1 7-11 10-15
6 35-40 47-54
17 13-16 18-22
1 7-11 10-15
11 35-40 47-54
14 35-40 47-54
11 50-55 68-75
14 40-50 54-68
6 50-55 68-75
13 40-50 54-68
14 40-50 54-68
20 80-100 108-136
L, M
N, O
P
Q
R
Illustration Reference
Tightening torque
D1, D2
E1, E2
1
Tightening Torque
3
Washer Assembly
2
Transducer Identication
4
Retaining Ring Assembly
7
Part Id Stamped
on this end
Transducers are not interchangeable, check part number.
Washer
Position
2
Gap
Gap
