TM12-1105-LG1
08/25/2017
EN
7.1 48E Series Performance Data:
48E Series Nutrunner - Air-LB Connector *
lb
f
×ft
Nm
lb
f
×ft
Nm in mm lbs kg in mm in mm
48EAE15AL3 11.1 15 2.2 3 2855 15.7 398 3.8 1.7 1.6 41 0.59 15 3/8"
48EAE28AL3 20.7 28 4.4 6 1300 16.2 410 4.1 1.9 1.6 41 0.59 15 3/8"
48EAE41AM3 30.2 41 6.6 9 1090 17.3 440 4.3 2.0 1.9 48 0.75 19 3/8"
48EAE58AM3 42.8 58 8.9 12 770 17.3 440 4.3 2.0 1.9 48 0.75 19 3/8"
48EAE58AM4 42.8 58 8.9 12 770 17.3 440 4.3 2.0 1.9 48 0.75 19 1/2"
48EAE90AH4 64.2 87 13.3 18 515 18.5 470 6.6 3.0 2.3 58 0.81 21 1/2"
48EAE105AH4 76.7 104 15.5 21 340 18.5 470 6.6 3.0 2.3 58 0.81 21 1/2"
48EAE135MH4 98.1 133 19.9 27 265 19.1 485 7.3 3.3 2.4 61 0.94 24 1/2"
48EAE175AX6 129.8 176 26.6 36 190 21.6 549 10.2 4.6 2.7 69 1.06 27 3/4"
48EAE230AX6 169.6 230 33.9 46 145 21.6 549 10.2 4.6 2.7 69 1.06 27 3/4"
48EAE37S231 27.2 37 5.9 8 1225 18.7 474 5.4 2.4 2.7 69 0.67 17 3/8"
48EAE52S231 38.3 52 8.1 11 860 18.7 474 5.4 2.4 2.7 69 0.67 17 3/8"
48EAE53S341 39.1 53 8.1 11 850 20.0 509 6.0 2.7 3.3 83 0.87 22 1/2"
48EAE75S341 55.3 75 11.0 15 600 20.0 509 6.0 2.7 3.3 83 0.87 22 1/2"
48EAE95S341 70.0 95 14.7 20 460 20.5 521 7.4 3.4 3.3 83 0.87 22 1/2"
48EAE110S341 81.1 110 16.9 23 400 20.5 521 7.4 3.4 3.3 83 0.87 22 1/2"
48EAE135S461 99.5 135 20.6 28 270 20.6 522 8.9 4.0 3.7 94 1.06 27 3/4"
48EAE230S461 169.6 230 34.6 47 150 22.2 563 10.6 4.8 3.7 94 1.06 27 3/4"
48EAE37F2 27.3 37 5.9 8 1225 18.7 474 5.4 2.4 1.7 43 0.67 17 ----
48EAE52F2 38.3 52 8.1 11 860 18.7 474 5.4 2.4 1.7 43 0.67 17 ----
48EAE53F3 39.0 53 8.1 11 850 20.0 509 6.0 2.7 2.3 59 0.87 22 ----
48EAE75F3 55.3 75 11.1 15 600 20.0 509 6.0 2.7 2.3 59 0.87 22 ----
48EAE110F3 81.1 110 17.0 23 400 20.5 521 7.4 3.4 2.3 59 0.87 22 ----
48EAE135F4 99.5 135 19.9 27 270 20.6 522 8.9 4.0 2.4 61 1.06 27 ----
48EAE230F4 172.6 230 34.7 47 150 22.2 563 10.6 4.8 2.4 61 1.06 27 ----
48EAE53H 39.8 54 8.1 11 850 20.2 512 7.9 3.6 2.4 61 1.06 27 ----
48EAE75H 56.8 77 11.1 15 600 20.2 512 7.9 3.6 2.4 61 1.06 27 ----
48EAE110H 85.6 115 17.0 23 400 20.2 512 8.9 4.0 2.4 61 1.06 27 ----
48EAE135H 101.8 135 20.7 28 270 20.6 522 8.9 4.0 2.4 61 1.06 27 ----
48EAE230H 169.6 230 34.7 47 150 22.2 563 10.6 4.8 2.4 61 1.06 27 ----
48ECE30C1 22.1 30 7.7 10 860 20.5 521 5.5 2.3 1.7 43 0.63 16 ----
48ECE30C3 22.1 30 7.7 10 860 20.5 521 5.5 2.3 1.6 40 0.63 16 ----
48EPE12Q 8.9 12 2.2 3 4000 8.3 211 2.7 1.2 ---- ---- 0.84 21 1/4" Hex
48EPE12D2 8.9 12 2.2 3 4000 7.7 196 2.7 1.2 ---- ---- 0.84 21 1/4"
48EPE25D3 18.4 25 4.4 6 1820 8.4 213 2.9 1.3 ---- ---- 0.84 21 3/8"
48EPE36D3 26.6 36 5.9 8 1290 8.4 213 2.9 1.3 ---- ---- 0.84 21 3/8"
48EPE48D3 35.4 48 7.4 10 985 8.6 218 3.0 1.4 ---- ---- 0.84 21 3/8"
48EPE65D4 47.9 65 9.6 13 750 10.8 274 5.0 2.3 ---- ---- 0.91 23 1/2"
48EPE90D4 66.4 90 14.0 19 510 11.3 287 5.3 2.4 ---- ---- 0.91 23 1/2"
48EPE125D4 92.2 125 19.2 26 360 11.3 287 5.3 2.4 ---- ---- 0.91 23 1/2"
48EPE150D4 110.6 150 22.9 31 240 11.3 287 5.3 2.4 ---- ---- 0.91 23 1/2"
48EPE200D6 144.0 195 92.0 125 180 16.2 410 9.5 4.3 ---- ---- 1.13 29 3/4"
48EPE500D6 368.0 500 225.0 300 53 16.2 410 9.8 4.5 ---- ---- 1.13 29 3/4"
48EPE1000D8 740.0 1000 370.0 500 33 19.2 486 16.2 7.3 ---- ---- 1.50 38 1"
* Note: 48E series Matrix tool connector specifications are the same.
** Note: Pin retainer models shown. Ball retainer models (termination B) specifications are the same.
48EA Series Right Angle Flush Socket Nutrunner
48EA Series Right Angle Hold & Drive Nutrunner
48EC Series Inine Crowfoot Nutrunner
48EP Series Pistol Grip Nutrunner **
Side to
Center
Ouput
Drive
Size
Max Torque
Min Torque
48EA Series Right Angle Nutrunner **
48EA Series Right Angle Floating Spindle Nutrunner
Model Number
Tool Range
Max.
Speed
(rpm)
Length Weight Head Height
