Cleco 48EAE15AL3 - Page 14

Page 14
TM12-1105-LG1
08/25/2017
EN
7.1 48E Series Performance Data (continued):
48E Series Nutrunner - Air-LB Tool Connector * (continued)
lb
f
×ft
Nm
lb
f
×ft
Nm in mm lbs kg in mm in mm
48ESE12Q 8.9 12 2.2 3 4000 13.5 343 3.0 1.4 --- --- 0.91 23 1/4" Hex
48ESE12D2 8.9 12 2.2 3 4000 13.0 330 3.0 1.4 --- --- 0.91 23 1/4"
48ESE25D3 18.4 25 4.4 6 1820 13.6 345 3.2 1.5 --- --- 0.91 23 3/8"
48ESE36D3 26.6 36 5.9 8 1290 13.6 345 3.2 1.5 --- --- 0.91 23 3/8"
48ESE48D3 35.4 48 7.4 10 985 13.8 351 3.3 1.5 --- --- 0.91 23 3/8"
48ESE65D4 47.9 65 9.6 13 750 16.6 420 5.3 2.4 --- --- 1.13 29 1/2"
48ESE90D4 66.4 90 14.0 19 510 17.1 435 5.6 2.5 --- --- 1.13 29 1/2"
48ESE125D4 92.2 125 19.2 26 360 17.1 435 5.6 2.5 --- --- 1.13 29 1/2"
48ESE150D4 110.6 150 22.9 31 240 17.1 435 5.6 2.5 --- --- 1.13 29 1/2"
48ESE12ZA 8.9 12 2.2 3 4000 16.7 425 3.4 1.5 --- --- 0.91 23 1/4"
48ESE271ZB 19.9 27 5.9 8 1820 22.0 559 5.8 2.6 --- --- 0.92 23 3/8"
48ESE361ZB 26.6 36 5.2 7 1290 22.0 559 5.8 2.6 --- --- 0.92 23 3/8"
48ESE602ZB 42.0 57 8.1 11 855 24.4 620 8.4 3.8 --- --- 1.10 28 1/2"
48ESE702ZB 50.2 68 10.3 14 570 24.4 620 8.4 3.8 --- --- 1.10 28 1/2"
48ESE802ZB 60.5 82 12.5 17 450 26.7 678 9.6 4.4 --- --- 1.10 28 1/2"
48ESE1152ZB 84.8 115 18.4 25 320 26.7 678 9.6 4.4 --- --- 1.10 28 1/2"
48ESE1502ZB 110.6 150 22.9 31 245 26.7 678 9.6 4.4 --- --- 1.10 28 1/2"
48ESE1653ZB 121.7 165 24.3 33 220 28.6 726 14.6 6.6 --- --- 1.57 40 3/4"
48ESE2503ZB 182.9 548 36.8 50 145 28.6 726 14.6 6.6 --- --- 1.57 40 3/4"
48ETE20T2 14.8 20 7.4 10 1425 16.9 430 4.4 2.0 --- --- 0.78 20 1/2"
48ETE30T3 22.1 30 11.1 15 1030 16.6 422 4.5 2.0 --- --- 0.83 21 3/4"
48ETE40T4 29.5 40 14.8 20 770 17.9 454 5.3 2.3 --- --- 1.18 30 1-1/16"
* Note: 48E series Matrix tool connector specifications are the same.
** Note: Pin retainer models shown. Ball retainer models (termination B) specifications are the same.
48ET Series Inline Tube Nut Nutrunner
Side to
Center
Ouput
Drive
Size
Max Torque
Min Torque
48ES Series Inine Nutrunner **
48ES Series Inline Floating Spindle Nutrunner
Model Number
Tool Range
Max.
Speed
(rpm)
Length Weight Head Height
