7.2 48E Series Tool Memory:
48E Series Nutrunner - Air-LB Tool Connector *
Model Number
Max Speed
[RPM]
Max Torque
[Nm]
Torque Cal
[NM]
Transducer
Type
Angle Cal
[PPD]
Static Current
Factor
[Nm/A]
48EAE15AL3 2855 15 17.9794 542846-12 29.8662 0.6929
48EAE28AL3 1300 28 42.8072 542846-31 65.6023 1.4458
48EAE41AM3 1090 41 50.9609 542846-31 78.0980 1.7212
48EAE58AM3 770 58 77.2838 542846-48 110.2015 2.4287
48EAE58AM4 770 58 77.2838 542846-48 110.2015 2.4287
48EAE90AH4 515 87 158.3540 542846-100 165.6771 3.6514
48EAE105AH4 340 104 156.6510 542846-100 248.0254 5.4662
48EAE135MH4 265 133 199.7300 542846-100 316.2324 6.9694
48EAE175AX6 190 176 231.2227 542846-40 441.5931 9.2456
48EAE230AX6 145 230 228.7037 542846-40 575.9910 12.0595
48EAE37S231 1225 37 45.8648 542846-31 70.2893 1.5491
48EAE52S231 860 52 69.5554 542846-48 99.1829 2.1859
48EAE53S341 850 53 65.5212 542846-31 100.4132 2.2130
48EAE75S341 600 75 99.3649 542846-48 141.6898 3.1226
48EAE95S341 460 95 98.2031 542846-48 185.5462 4.0892
48EAE110S341 400 110 203.5980 542846-100 213.0167 4.6946
48EAE135S461 270 135 201.4084 542846-100 318.8948 7.0280
48EAE230S461 150 230 297.2863 542846-40 567.7714 11.8873
48EAE37F2 1225 37 45.8648 542846-31 70.2893 1.5491
48EAE52F2 860 52 69.5554 542846-48 99.1829 2.1859
48EAE53F3 850 53 65.5212 542846-31 100.4132 2.2130
48EAE75F3 600 75 99.3649 542846-48 141.6898 3.1226
48EAE110F3 400 110 203.5980 542846-100 213.0167 4.6946
48EAE135F4 270 135 201.4084 542846-100 318.8948 7.0280
48EAE230F4 150 230 297.2863 542846-40 567.7714 11.8873
48EAE53H 850 54 65.5212 542846-31 100.4132 2.2130
48EAE75H 600 77 99.3649 542846-48 141.6898 3.1226
48EAE110H 400 115 203.5980 542846-100 213.0167 4.6946
48EAE135H 270 135 201.4084 542846-100 318.8948 7.0280
48EAE230H 150 230 297.2863 542846-40 567.7714 11.8873
48ECE30C1 860 30 49.1424 542846-48 99.1829 1.5444
48ECE30C3 860 30 49.1424 542846-48 99.1829 1.5444
48EPE12Q 4000 12 13.9592 542846-12 21.3330 0.5379
48EPE12D2 4000 12 13.9592 542846-12 21.3330 0.5379
48EPE25D3 1820 25 33.2354 542846-31 46.8588 1.1225
48EPE36D3 1290 36 37.8018 542846-36 66.1209 1.5840
48EPE48D3 985 48 49.8132 542846-48 86.5869 2.0742
48EPE65D4 750 65 70.3865 542846-12 113.2308 2.7124
48EPE90D4 510 90 111.9428 542846-31 166.1383 3.7809
48EPE125D4 360 125 127.3235 542846-36 234.4323 5.3350
48EPE150D4 240 150 190.6085 542846-36 350.9548 7.9868
48EPE200D6 178 200 282.9741 542846.12 479.1795 10.9048
48EPE500D6 53 500 903.0329 542846-12 1609.6500 34.7997
48EPE1000D8 33 1000 1449.6660 542846-12 2584.0198 55.8650
* Note: 48E series Matrix tool connector specifications are the same.
** Note: Pin retainer models shown. Ball retainer models (termination B) specifications are the same.
48EA Series Right Angle Flush Socket Nutrunner
48EA Series Right Angle Nutrunner **
48EA Series Right Angle Floating Spindle Nutrunner
48EP Series Pistol Grip Nutrunner **
48EA Series Right Angle Hold & Drive Nutrunner
48EC Series Inline Crowfoot Nutrunner
