7.2 48E Series Tool Memory (continued):
48E Series Nutrunner - Air-LB Tool Connector * (continued)
Model Number
Max Speed
[RPM]
Max Torque
[Nm]
Torque Cal
[NM]
Transducer
Type
Angle Cal
[PPD]
Static Current
Factor
[Nm/A]
48ESE12Q 4000 12 13.9592 542846-12 21.3330 0.5379
48ESE12D2 4000 12 13.9592 542846-12 21.3330 0.5379
48ESE25D3 1820 25 33.2354 542846-31 46.8588 1.1225
48ESE36D3 1290 36 37.8018 542846-36 66.1209 1.5840
48ESE48D3 985 48 49.8132 542846-48 86.5869 2.0742
48ESE65D4 750 65 70.3865 542846-12 113.2308 2.7124
48ESE90D4 510 90 111.9428 542846-31 166.1383 3.7809
48ESE125D4 360 125 127.3235 542846-36 234.4323 5.3350
48ESE150D4 240 150 190.6085 542846-36 350.9548 7.9868
48ESE12ZA 4000 12 13.9592 542846-12 21.3333 0.5379
48ESE271ZB 1820 27 33.2354 542846-31 46.8595 1.1225
48ESE361ZB 1290 36 37.8018 542846-36 66.1219 1.5840
48ESE602ZB 855 57 103.2743 542846-100 99.4078 2.3813
48ESE702ZB 570 68 102.1637 542846-100 148.8176 3.5649
48ESE802ZB 450 82 153.7513 542846-40 188.3146 4.2855
48ESE1152ZB 320 115 150.7974 542846-40 264.9600 6.0298
48ESE1502ZB 245 150 149.1546 542846-40 345.6000 7.8649
48ESE1653ZB 220 165 376.0907 542846-100 381.0632 8.6720
48ESE2503ZB 145 548 372.0461 542846-100 570.4674 12.9823
48ETE20T2 1425 20 35.9914 542846-17 59.7333 0.9790
48ETE30T3 1030 30 49.8343 542846-17 82.7077 1.3556
48ETE40T4 770 40 66.4457 542846-17 110.2769 1.8075
* Note: 48E series Matrix tool connector specifications are the same.
** Note: Pin retainer models shown. Ball retainer models (termination B) specifications are the same.
48ES Series Inline Nutrunner **
48ES Series Inline Floating Spindle Nutrunner
48ET Series Inline Tube Nut Nutrunner
