Clenergy SPH Installation and Operation Manual
1.3. SPH50 & SPH60
Front view Bottom view
Display and connections
External protective earth (PE)-terminal
Display information switch
LCD Display: Showing the
inverter status
Operation LED,
Blue, Working Mode
Operation LED, Red,
fault status
AC connector
Optional communication
slot: SNMP and RS485
USB
RS232
Solar panel input
(DC)
