1. Input power cord;
2. Hydraulic circuit breaker;
3. NMC Module;
4. LCD screen;
5. RUN:Operation indicator;
KWH:Energy pulse indicator;
ALM:Alarm indicator;
6. UP:Scroll up to the previous page；
7. DOWN:Scroll down to the next page;
8. CONTROL:Confirm and flip button;
9. RESET: Reset button;
10. NET: 10/100M Ethernet port;
11. SER: Serial port（MODBUS Supported);
12. IN: Daisy-Chain port；Connect to the OUT port of
previous PDU；
13. OUT: Daisy-Chain port; Connect to the IN port of
next PDU
14. T/H1:Ttemperature and humidity sensor port 1;
T/H2:Ttemperature and humidity sensor port 2;
15. Alarm:Audible and visual alarm port
16. Outlet LED indicator；
17. Output sockets；
18. Replaceable outlet modules;
