4.3 Installation
Vertical-mounting (0U)
Both the NMC Module and output module are Hot-Swappable.
CAUTION:
1. Request a qualified electrician to change the NMC Module or Output Module.
2. To prevent electrical shock and ensure the personal safety, please do switch off the corresponding
circuit breaker before replacing the Output Module as the output module chassis is with strong
electricity.
3. Please notice the install direction of the Output Module and don’t mount it in a reverse direction.
4. Do not replace the Outlet Module when there is load.
5. The Manufacturer is not responsible for the damage or claims resulting from
faulty or incorrect use of its Products.
5 Hardware instruction
5.1 NMC module
Item
Function
Instruction
RUN
RUN indicator
Status: flashing every second
KWH
kWh indicator
Status: flashing frequency depends on the connected load
ALM
Alarm indicator
Status: flashing when threshold is exceeded.
NET
Ethernet port
LAN/WAN communication port
SER
Serial port
RS-485 Serial communication port
IN
Daisy-Chain port
Connect to the Out port of previous PDU
OUT
Daisy-Chain port
Connect to the IN port of next PDU
CONTROL
Control button
Press to view the Rack PDU status and configuration.
Restore to factory settings: Press and hold the CONTROL
button, then press RESET button to restore to factory settings
UP
Page UP
Scroll up to the previous page
DOWN
Page Down
Scroll down to the next page
RESET
RESET button
Restart system
LCD screen
View the data status
Display the power data and alarm status
T/H
Temperature/humidity
sensor port
Connect to temperature/humidity sensors
