Interface (Ports & Jacks)
Interface (Ports & Jacks) A - 3
A
e-SATA Port This e-SATA (external Serial Advanced Technology Attachment) port allows you to plug-in
external Serial ATA hard drives.
HDMI-IN Port
Factory Option
The HDMI-In (High-Definition Multimedia Interface) port allows you to display external sources
such as Blu-ray players, DVDs, set top boxes and games consoles etc. on your computer screen
(see “HDMI-In Module” on page 7 - 51). The HDMI-In port is enabled with the optional
(Factory Option) HDMI-In Module only.
HDMI-Out Port The HDMI-Out (High-Definition Multimedia Interface) port is an audio/video connector
interface for transmitting uncompressed digital streams. This allows you to connect an external
monitor, TV or Flat Panel Display etc. as a display device (see “Configuring an External
Display using the NVIDIA Control Panel” on page B - 7) by means of a HDMI cable. Note that
HDMI carries both audio and video signals (see “HDMI Audio Configuration” on page 2 -
8).
Headphone-Out Jack Headphones or speakers may be connected through this jack. Note: Set your system’s volume
to a reduced level before connecting to this jack.
Line-In Jack The Line-In jack allows you to play audio sources through the computer’s speakers. Note that
audio input through Line-in will default to the mute setting. To set up your audio sources to play
through the Line-in jack go to the Sound control panel and make sure the Mute box is not
ticked.
Item Description
To Next Page
