Clevo NH58AF1 - Component Removal Procedures

Disassembly
Removing the Battery 2 - 5
2.Disassembly
Removing the Battery
1. Turn the computer off, and turn it over.
2. Remove the screws - (Figure 1a).
3. Carefully lift the battery in the direction of the arrow (Figure 1b).
4. Remove the battery out of the compartment (Figure 1c
)
.
1 2
3
3
Figure 1
Battery Removal
a. Remove the screws.
b. Lift the battery.
c. Remove the battery.
1
a.
c.
3
b.
3
2
3. Battery
• 2 Screws
