Clevo NH58AF1 User Manual

Disassembly
2 - 6 Removing the Hard Disk Drive
2.Disassembly
Removing the Hard Disk Drive
The hard disk drive can be taken out to accommodate other 2.5" serial (SATA) hard disk drives with a height of 7mm
(h). Follow your operating system’s installation instructions, and install all necessary drivers and utilities (as outlined in
Chapter 4 of the User’s Manual) when setting up a new hard disk.
Hard Disk Disassembly Process
1. Turn off the computer, and remove the battery (page 2 - 5).
2. Remove the screws - (Figure 2a).
3. Carefully slide the bottom case as shown and lift it off (Figure 2b
)
.
4. The HDD will be visible at point on the mainboard (Figure 2c
)
.
1 5
6 7
8
2
a.
b.
3
5
4
6
8
7
c.
6
1
Figure 2
HDD Assembly
Removal
a. Remove the screws.
b. Slide the bottom case
out and remove it.
c. Locate the HDD.
6. Bottom Case
• 5 Screws
